Raspberry Pi Camera Module, Supports Night Vision

Features



  • Raspberry Pi Night Vision Camera, supports all revisions of the Pi

  • 5 megapixel OV5647 sensor

  • Adjustable focus distance

  • Camera specifications

    • CCD size : 1/4inch

    • Aperture (F) : 1.8

    • Focal Length : 3.6mm

    • Angle of View (diagonal) : 75 degree

    • Sensor best resolution : 1080p



  • 4 screw holes

    • Used for attachment

    • Provides 3.3V power output

    • Supports connecting infrared LED and/or fill flash LED



  • Dimension : 25mm x 24mm


Note: to use the camera with Raspberry Pi Zero / Zero W / Zero WH, you need to buy a specific cable: Raspberry Pi Zero v1.3 Camera Cable


Selection Guide


rpi-camera-v2-3






  1. The recommendation is considered from sales report and cost performance.

  2. While normal IR cameras will take curious reddish pictures by daylight for lacking of IR filter in the CCD, the RPi IR-CUT Camera can take better pictures in correct color by daylight, and still features the ability to see in the dark.

  3. RPi Zero V1.3 Camera supports only Raspberry Pi Zero V1.3Raspberry Pi Zero W, and Raspberry Pi Zero WH


Weight: 0.059 kg


Package Content:



The included FFC is 16cm, if you need a longer cable, please consider: RPi Camera Cable 60cm



  1. RPi Camera (F) x1

  2. Infrared LED Board (B) x2

  3. 15-pin FFC (opposite sides contact) x1
