Industrial Short Path Steam Vacuum Distillation Equipment Essential Oil Distiller
Product Description
Molecular distillation is considered as the safest mode of separation and to purify the thermally unstable molecules and related compounds with low volatility and elevated boiling point.
The process distinguishes the short residence time in the zone of the molecular evaporator exposed to heat and low operating temperature due to vacuum in the space of distillation.
Product Paramenters
Model | GMD-150 |
Estimate Throughtput at End of 8-10 hr. day for CBD | 20kg |
1Effective Evaporation Area | 0.25㎡ |
Motor Power | 120w |
Maximum Speed | 350rpm |
Barrel Diameter | 150mm |
Feeding Funnel Volume | 3L |
Dimension (W x H x D) | 2270 x 228 x 1940mm |
Internal Condenser Area | 0.4㎡ |
Jacketed Feeding Vessel Volume | 3L |
Distillate Receiving Vessel Volume | 5L |
Residue Receiving Vessel Volume | 3L |
Stirrer Seal | Oil-less Magnetic, High Vacuum |
Wiper | PTFE Scraper |
Structure Material | Borosilicate Glass 3.3 |
Vacuum Gauge | Pirani style |
Operation Temperature | Up to 250℃ |
Vacuum Level | Better than 10 Pa |
Voltage | 220V-single phase |
Details Images
Control System
Accurate data,detailed display,easy and safe operation.
High evaporation efficiency and reduced retention time with minimum time delay.
Molecular distillation is made by high borosilicate glass and PTFE, which have excellent corrosion resistance.
Diffusion Pump
Increase vacuum efficiency and higher vacuum.
High-precision distillation barrel allows the liquid to form a complete and unified thin film on the heated surface. The inner surface is smooth to avoid stick and scaling.
Scraper Model and self-cleaning roller model film forming system are available.
Glass/PTFE Valve
Guarantee the continuity of collection, higer collection rate and better automation.
The barrel of the distiller has glass and stainless steel material for selection.
Magnetic force transmission make film forming system separate from motor. The whole system performs a completed sealing. Minimum Vacuum degree can reach 0.001mba.
