Product Description

    ACR123U with LCD Visual USB contactless RFID Reader Writer



Physical Characteristics
Dimensions (mm) Main Body: 159.0 mm (L) x 100.0 mm (W) x 21.0 mm (H)
With Stand: 177.4 mm (L) x 100.0 mm (W) x 94.5 mm (H)
Weight (g) Main Body: 281 g
With Stand: 506 g
USB Interface
Protocol USB CCID
Connector Type Standard Type A
Power Source From USB Port
Speed USB Full Speed (12 Mbps)
Cable Length 1.5 m, Fixed
Contactless Smart Card Interface
Standard ISO 14443 A & B Parts 1-4
Protocol ISO 14443-4 Compliant Card, T=CL
MIFARE® Classic Card, T=CL
SAM Card Interface
Number of Slots 3 Standard SIM-sized Card Slots
Standard ISO 7816 Class A, B, C (5 V, 3 V, 1.8 V)
Protocol T=0; T=1
Built-in Peripherals
LCD Graphical LCD with White Backlight
Resolution : 128 x 64 pixels
Number of Characters: 16 characters x 8 lines
LED 4 single-color: Blue, Yellow, Green and Red
Tapping Region Tri-color backlight: Red, Green and Blue
Speaker Audio Tone Indication
Other Features
Security Tamper Switch (Internal anti-intrusion detections and protection)
Firmware Upgrade Supported
Real-time Clock Supported
Certifications/Compliance
Certifications/Compliance ISO 14443
ISO 7816 (SAM Slot)
USB Full Speed
PC/SC
CCID
VCCI (Japan)
KC (Korea)
Microsoft® WHQL
CE
FCC
RoHS 2
REACH
Device Driver Operating System Support
Device Driver Operating System Support Windows® CE
Windows®
Linux®
Solaris

The ACR123U is the USB version of the ACR123S, a cost-effective, flexible and intelligent contactless reader. It can be integrated to existing (Point-of-Sale) terminals or cash registers, to offer the convenience of a cashless payment system. The ACR123U speeds up movement in checkout counters, by enabling customers to complete payments by simply tapping their cards.

The ACR123U is equipped with a large graphical LCD that allows merchants to display messages, as well as a large tapping area with backlight, which guides customers in carrying out their payment transactions. Developed based on 13.56 MHz contactless (RFID) technology, it supports any contactless card following the ISO 14443-4 standard. It is also equipped with a large graphical LCD, as well as a large user-controllable tapping area with backlight.
