Outstanding quality card printer

Avansia is a Retransfer technology direct-to-card printer for very high quality card delivery. Designed for rigorous use, Avansia is extremely robust and provides high security card issuance.
Capable of issuing more than 140 single-sided color cards per hour, it is ideal for card issuance in medium and large quantities.

Avansia is ideal for delivering:

• Corporate ID cards
• Secure access badges
• Student cards
• Payment cards
• Loyalty cards / gift cards
• National ID cards
• Driver’s licenses

A Retransfer printer designed for heavyduty card issuance activities

Flawless printing

Retransfer technology (Reverse Transfer) maximizes print quality:

• High resolution 600 dpi: images and text are rendered perfectly and micro-text and watermarks are printed in high definition.
• Over the edge printing: this printer will guarantee that your edges print perfectly since the film fully covers the card.
• Evolis High Trust® consumables : their use provides flawless results.

Increased productivity

Avansia is exceptionnaly fast with an output of more than 140 single-sided color cards per hour.
Thanks to the high capacity feed tray and output tray (250 cards each) - and high capacity consumables (500 prints per roll), you can print your card runs with no interruptions.

Card issuance secured

Media compatibility

The Avansia Retransfer technology can print on all types of cards (PVC, PET, polycarbonate, ABS), including uneven card surfaces, such as smart contact and contactless cards.
The standard built-in card flattener delivers perfect results.

Multiple encoding options

To meet your specific needs, Avansia can be configured for all types of data encoding options: magnetic stripe, contact and contactless smart cards. These factory-configured encoding options can be combined.

Enhanced security

Avansia can be easily locked by removing the RFID electronic key. This quite simply prevents any attempt to use the printer. A mecanical key lock, available as an option, prevents access to consumables. Moreover, Avansia comes with a security slot (Kensington® type).

 General features

• Reverse transfer printing, using color dye sublimation and resin monochrome retransfer
• Dual-sided printing (standard)
• Over the edge printing
• Using color dye sublimation and resin monochrome retransfer
• 600 dpi print head (23.6 dots/mm)
• Bitmap: 24 bits, 16 million colors
• Printout: Y/M/C 256 level
• 64 MB of memory (RAM)

Printing performances

• Full card:



  • Single side (YMCK): 25 s/card - 144 cards/hour
  • Dual side (YMCKK): 37.5 s/card - 96 cards/hour

Additional encoding modules

• Available modules:



  • Magnetic stripe encoder ISO 7811
  • Dual contact and contacless encoder
• Encoder connectivity: internal USB hub, 1 port available
• Encoding options can be combined
• Factory installed or installed on site for contact and contactless encoders

Interfaces

• USB (1.0, 1.1, 2.0, 3.0), cable supplied
• Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led)

Safety

• RFID locking key
• Support for security lock (Kensington® type)
• Centralized locking system to secure access to blank cards, ribbon and film (optional)
• IPSec encrypted networking security

Card management and specifications

• Card feeder: 250 cards (0.76 mm – 30 mil)
• Card output hopper: 250 cards (0.76 mm – 30 mil)
• Reject tray capacity: 30 cards (0.76 mm – 30 mil)
• Card thickness: 0.76 mm (30 mil), manual adjustment
• Card types:
  • PVC cards
  • Composite PVC cards
  • PET-F cards
  • PET-G cards
  • Polycarbonate cards (PC)
  • ABS cards
• Card format: ISO CR80 - ISO 7810 (53.98 x 85.60 mm –  3.370” x 2.125”)


Evolis High Trust® Ribbons

To maximize the quality and durability of printed cards, the lifespan of the print head and the overall printer reliability, use Evolis High Trust® ribbons.
Ribbon capacity:

• Clear transfer film: 500 prints/roll
• Holographic transfer film: 400 prints/roll
• YMCK: 500 prints/roll
• YMCKK: 400 prints/roll
• YMCKI ribbon (for smart cards, magnetic stripes and signature panels): 400 prints/roll
• YMCKH ribbon (for non PVC cards): 400 prints/roll
• YMCFK ribbon (F = UV ink): 400 prints/roll

Software

• Compatible with Windows® (32/64 bits): XP SP3, Vista, W7, W8
• Delivered with cardPresso XXS for designing and editing badges
  • Internal database (unlimited records)
  • Windows® (from XP onwards)

Display

• Two-line LCD display and LED status indicator
• Printer graphical notifications: empty input hopper, empty/low level ribbon alert...

Certifications and statement of compliance

• RoHS
• CE, FCC, UL, IEC

Size and weight

• Dimensions (H x W x D): 436 x 340 x 297 mm (17.16” x 13.38” x 11.69”)
• Weight: 20 kg (44.09 lbs)

Packaging: Packaging carton: 590 x 460 x 490 mm,Weight: 25 kg (excluding optional built-in items)

Leading Time: Within 1 to 2 days after order
