Шейкер для водяной ванны серии SHZ

Water Bath Shaker/Air bath Shaker

APPLICABLE SCOPE:
The shaker is widely used in experiments of pharmacy, such as germ culture, ferment, hybridization, and research of biochemical reaction, enzyme and cellular tissue. It has a wide and important range of applications in research of medicine, biology, numerator, pharmacy and environmental protection.

PRODUCT CHARACTERISTICS:
Microprocessor temperature and frequency controller (C Series) with the functions of timer and speed governing;
The working chamber is made of stainless steel which is easy to clean;
Be equipped with advanced universal clamp.

Main features of water bath oscillator:
1. Temperature control accurate digital display.
2, there are small waves when oscillating, but no spray splashes.
3, with mechanical timing.
4. Universal spring test bottle holder is particularly suitable for the preparation of biological samples for various comparative tests.
5. Stepless speed regulation, stable operation, simple and safe operation.
6. The inner cavity is made of stainless steel and has good corrosion resistance.

How it works
1. Cyclic oscillation: This method of operation is also called circular oscillation. It rotates and oscillates 360 ° on the horizontal plane. For example, when it works in this way, the oscillated liquid is vortexed in the container to achieve a uniform effect.
2. Reciprocating oscillation: As the name implies, it reciprocates when oscillating, and uses inertia to oscillate the sample. Why use this oscillation method? Because when the viscosity of the liquid is relatively thick, the effect of this oscillation method is much better than that of convoluted oscillation.
3. dual-function oscillation: that is, the combination of two modes of swing and reciprocating oscillation. Depending on the sample properties and work requirements, you can choose any work method.

Instructions for use
1. Load the test bottle and keep the balance. If it is a dual function model, set the oscillation mode. (See the last picture for detailed settings)
2. Turn on the power and set the timing time according to the scale on the surface of the machine. If you need to work for a long time, set the timer to the "normally open" position.
3. Turn on the power switch and set the constant temperature:
(1) Set the small control switch to the "Settings" section. At this time, the temperature displayed on the display is the set temperature. Adjust the knob to set the temperature you need for your work. (The working temperature you set should be higher than the ambient temperature. At this time, the machine starts to heat up and the yellow indicator light is on, otherwise the machine will not work)
(2) Set the small switch of the control part to the "Measuring" side. At this time, the temperature displayed on the display screen is the actual temperature of the air in the test box. As the air temperature in the box changes, the displayed number will change accordingly.
(3) When the heating reaches your desired temperature, the heating will automatically stop and the green indicator light will be on; when the heat in the test chamber is lower than the temperature you set, a new round of heating will start again.
4. Turn on the oscillation device:
(1) Turn on the oscillation switch on the control panel, and the indicator light is on.
(2) Adjust the oscillation speed knob to the desired oscillation frequency.
5, cut off the power after work, set the speed control knob and temperature control knob to the lowest point.
6. Clean the machine and keep it clean .

Operational Notes
1. The work surface of the machine must not be excessively smooth.
2. The whole machine is strictly forbidden to use in direct sunlight.
3. The speed regulation should start slowly from low speed to high speed.
4. The machine oscillates at high speed so that someone needs to be in charge.
5. The heating tube should be completely immersed in water to prevent dry burning.
6. The amount of water added should be higher than the heating tube and lower than the spring.

Notes edit
1. The appliance should be placed on a solid work surface, and the environment should be clean and tidy, and well ventilated.
2. The power socket provided by the user should have good grounding measures.
3. It is strictly forbidden to move the machine during normal work.
4. Never hit objects with the machine.
5. It is strictly forbidden for children to approach the machine to prevent accidents.
6. Make sure the power supply is cut off before replacing the fuse.
7. Please clean the machine after use, no water drops or dirt residues
