Испытательное оборудование для литиевой батареи, для эксперимента по разделению
115,00 $ - 120,00 $
Высококачественная батарея 1254 60 мАч литиевая кнопочного типа
- Категория: >>>
- Поставщик: Shenzhen Sinoming Technology Co. Ltd.
Сохранить в закладки 62457324710:
Описание и отзывы
Характеристики
High quality 1254 60mah button type lithium battery
Battery parameters:
Item | Specifications | |
Nominal capacity | 60MAH | |
Nominal voltage | 3.8V | |
Charge current | Standard Charge :0.2C Rapid charge :0.5C | |
| Standard Charging method | 0.2CCC(constant current)charge to 4.2V,then CV(constant voltage 4.2V)charge till charge current decline to≤0.01C |
Charging time | Standard Charging Approx6 hours Rapid charge Approx3hours | |
Max.charge current | Constant Current 1CConstant Voltage 4.2V 0.01 C cut-off | |
Max.discharge current | Constant current 20 Cend voltage3.0V | |
Standard Discharge Current | Constant current 0.2 C end voltage3.0V | |
1C capacity multiplying power 1C | ≥92% | |
1Cdischarge Efficiency 1 | ≥98% | |
| Discharge cut-off voltage | 3.0V |
| Charge cut-off Voltage | 4.35V |
Impedance | ≤400mΩ | |
Cell Dimension | L:12mm,T:5.4mm | |
| Operating temperature | Charging:0℃~45℃ Discharging:-20℃~60℃ |
| Storage temperature | -10℃~45℃ |
Storage Humidity | ≤75% RH | |
Appearance | Without scratch,distortion,contamination and leakage |
1254 battery picture:
(15mAh-1000mAh) Partial Li-polymer cell model list:
| General type battery-Small Capacity cells 3.7V (15-1000mAh) | |||||||
| Model No | Norminal Capacity | Norminal Voltage | Cell Demensions(mm) | Internal Resistance(omh) | Approximate weight(g) | ||
| Thickness | Width | Height | |||||
| HJL300815 | 15 | 3.7 | 3.0 | 8 | 14 | 600 | 0.6 |
| HJL271323 | 38 | 3.7 | 2.7 | 13 | 23 | 550 | 1 |
| HJL351121 | 40 | 3.7 | 3.5 | 11 | 21 | 500 | 1.2 |
| HJL381120 | 41 | 3.7 | 3.9 | 11 | 20.5 | 500 | 1.2 |
| HJL501020 | 45 | 3.7 | 5.1 | 10 | 20 | 380 | 0.9 |
| HJL531017 | 50 | 3.7 | 5.3 | 10 | 17 | 400 | 1.3 |
| HJL451020 | 50 | 3.7 | 4.5 | 10 | 20 | 400 | 1.3 |
| HJL401120 | 50 | 3.7 | 4.0 | 11 | 21 | 400 | 1.3 |
| HJL401121 | 50 | 3.7 | 4.0 | 11 | 21 | 400 | 1.3 |
| HJL501121 | 60 | 3.7 | 5.0 | 11 | 21 | 350 | 1.2 |
| HJL421220 | 65 | 3.7 | 4.2 | 12 | 20 | 350 | 1.5 |
| HJL451220 | 65 | 3.7 | 4.7 | 12.5 | 20.5 | 350 | 1.5 |
| HJL301230 | 70 | 3.7 | 3.0 | 12 | 30 | 250 | 1.6 |
| HJL401225 | 70 | 3.7 | 4 | 12.5 | 25.5 | 250 | 1.6 |
| HJL361320 | 72 | 3.7 | 3.9 | 13.3 | 20.5 | 350 | 1.9 |
| HJL401620 | 80 | 3.7 | 4 | 16.5 | 20.5 | 250 | 3 |
| HJL350846 | 80 | 3.7 | 3.5 | 8 | 46 | 250 | 2 |
| HJL401225 | 80 | 3.7 | 4.0 | 12 | 25 | 250 | 2 |
| HJL451320 | 80 | 3.7 | 4.5 | 20.5 | 13 | 250 | 2 |
| HJL401226 | 80 | 3.7 | 4.0 | 12 | 26 | 250 | 2 |
| HJL451620 | 85 | 3.7 | 4.5 | 16.5 | 30.5 | 250 | 2 |
| HJL451225 | 85 | 3.7 | 4.5 | 12 | 25 | 300 | 1.9 |
| HJL451225 | 90 | 3.7 | 4.5 | 12.5 | 25.5 | 250 | 2.3 |
| HJL322121 | 95 | 3.7 | 3.2 | 21.5 | 21.5 | 250 | 2.5 |
| HJL521225 | 100 | 3.7 | 5.3 | 12 | 25 | 250 | 2.5 |
| HJL551420 | 100 | 3.7 | 5.5 | 14.5 | 39 | 250 | 2.5 |
| HJL401230 | 102 | 3.7 | 4.1 | 12 | 28.5 | 250 | 2.6 |
| HJL401430 | 110 | 3.7 | 4.2 | 14.5 | 30.5 | 300 | 2.6 |
| HJL481133 | 120 | 3.7 | 4.8 | 11 | 33 | 220 | 3 |
| HJL401235 | 120 | 3.7 | 4.0 | 12 | 35 | 220 | 3 |
| HJL501230 | 120 | 3.7 | 5.0 | 12 | 30 | 220 | 3 |
| HJL401235 | 120 | 3.7 | 4.0 | 12 | 35 | 220 | 3 |
| HJL401039 | 132 | 3.7 | 4.3 | 10.2 | 25.5 | 200 | 2.9 |
| HJL501230 | 140 | 3.7 | 5 | 12.5 | 30.5 | 200 | 3.4 |
| HJL402025 | 150 | 3.7 | 4 | 20.5 | 33.5 | 150 | 3.2 |
| HJL402030 | 180 | 3.7 | 4.2 | 20.5 | 30.5 | 200 | 3.8 |
| HJL402033 | 190 | 3.7 | 3.95 | 20.5 | 33.5 | 150 | 3.9 |
| HJL501730 | 200 | 3.7 | 5 | 16.7 | 30.5 | 200 | 4.5 |
| HJL352730 | 200 | 3.7 | 3.5 | 27 | 30 | 200 | 4.5 |
| HJL451834 | 210 | 3.7 | 4.6 | 18.5 | 34.5 | 150 | 4.5 |
| HJL581730 | 240 | 3.7 | 6 | 17.5 | 30.5 | 125 | 5.1 |
| HJL502030 | 250 | 3.7 | 5.2 | 20.5 | 30.5 | 200 | 5.1 |
| HJL422435 | 280 | 3.7 | 4.1 | 24 | 35 | 120 | 5.8 |
| HJL452730 | 280 | 3.7 | 4.5 | 27 | 30 | 120 | 5.8 |
| HJL451941 | 300 | 3.7 | 4.5 | 19 | 43 | 150 | 6.2 |
| HJL323435 | 320 | 3.7 | 3.25 | 33.8 | 35.5 | 150 | 6.4 |
| HJL392338 | 320 | 3.7 | 4.2 | 23.5 | 38.5 | 150 | 6.4 |
| HJL503029 | 350 | 3.7 | 4.9 | 30.5 | 29.5 | 150 | 6.8 |
| HJL502730 | 350 | 3.7 | 5.0 | 27 | 30 | 150 | 6.8 |
| HJL502535 | 360 | 3.7 | 5.6 | 25.5 | 35.5 | 150 | 7.3 |
| HJL353040 | 370 | 3.7 | 3.5 | 30 | 40 | 100 | 7.5 |
| HJL402546 | 390 | 3.7 | 4.2 | 25.5 | 46.5 | 100 | 7.8 |
| HJL352745 | 400 | 3.7 | 3.5 | 27 | 46 | 70 | 8.5 |
| HJL352745 | 400 | 3.7 | 3.5 | 27 | 45 | 70 | 8.5 |
| HJL303048 | 400 | 3.7 | 3.0 | 30 | 48 | 70 | 8.5 |
| HJL403040 | 430 | 3.7 | 4.0 | 30 | 40 | 80 | 8.6 |
| HJL503030 | 430 | 3.7 | 5.0 | 30 | 30 | 80 | 8.6 |
| HJL602535 | 450 | 3.7 | 6.0 | 25.5 | 35.5 | 100 | 8.7 |
| HJL503034 | 450 | 3.7 | 5.0 | 30 | 34 | 100 | 9 |
| HJL603030 | 470 | 3.7 | 6.0 | 30 | 30 | 60 | 10 |
| HJL303450 | 490 | 3.7 | 3.0 | 34 | 50 | 80 | 9.3 |
| HJL502248 | 500 | 3.7 | 5.0 | 22.5 | 48.5 | 120 | 9.6 |
| HJL483637 | 500 | 3.7 | 4.8 | 36.5 | 37.5 | 110 | 9.7 |
| HJL423043 | 500 | 3.7 | 4.2 | 30 | 43 | 120 | 9.8 |
| HJL274346 | 510 | 3.7 | 2.7 | 43 | 46 | 80 | 9.9 |
| HJL632140 | 520 | 3.7 | 6.3 | 21.5 | 40.5 | 80 | 10.2 |
| HJL354640 | 580 | 3.7 | 3.6 | 46 | 40 | 100 | 11.6 |
| HJL503043 | 600 | 3.7 | 5.0 | 30 | 43 | 100 | 12 |
| HJL403048 | 600 | 3.7 | 4.1 | 30 | 48 | 100 | 12 |
| HJL303759 | 600 | 3.7 | 3.0 | 37 | 59 | 100 | 12 |
| HJL483438 | 600 | 3.7 | 4.8 | 34 | 38 | 100 | 12 |
| HJL502845 | 600 | 3.7 | 5.0 | 28 | 45 | 100 | 12 |
| HJL452853 | 640 | 3.7 | 4.5 | 28 | 53 | 100 | 12.4 |
| HJL553444 | 640 | 3.7 | 5.5 | 34 | 44 | 80 | 13 |
| HJL383450 | 650 | 3.7 | 3.8 | 34 | 50 | 80 | 13 |
| HJL603040 | 650 | 3.7 | 6.0 | 30 | 40 | 80 | 13 |
| HJL553040 | 650 | 3.7 | 5.5 | 30 | 40 | 80 | 13 |
| HJL652447 | 700 | 3.7 | 6.5 | 24.5 | 47.5 | 80 | 15 |
| HJL553345 | 700 | 3.7 | 5.5 | 33 | 45 | 80 | 14 |
| HJL503048 | 700 | 3.7 | 5.0 | 30 | 48 | 80 | 14 |
| HJL603245 | 710 | 3.7 | 6.0 | 32 | 45 | 60 | 13.6 |
| HJL553440 | 730 | 3.7 | 5.5 | 34 | 40 | 80 | 15 |
| HJL603440 | 730 | 3.7 | 6.0 | 34 | 40 | 80 | 15 |
| HJL653040 | 750 | 3.7 | 6.5 | 30 | 40 | 70 | 15 |
| HJL423450 | 750 | 3.7 | 4.2 | 34 | 50 | 70 | 15 |
| HJL653438 | 800 | 3.7 | 6.5 | 34 | 38 | 60 | 15.7 |
| HJL653439 | 800 | 3.7 | 6.5 | 34 | 39 | 60 | 15.7 |
| HJL453450 | 800 | 3.7 | 4.5 | 34 | 50 | 60 | 15.7 |
| HJL573639 | 800 | 3.7 | 5.7 | 36 | 39 | 60 | 15.7 |
| HJL722842 | 800 | 3.7 | 7.4 | 28 | 42 | 60 | 15.7 |
| HJL523448 | 800 | 3.7 | 5.3 | 34 | 48 | 60 | 15.7 |
| HJL483450 | 850 | 3.7 | 4.8 | 34 | 50 | 80 | 15.5 |
| HJL503450 | 850 | 3.7 | 5.0 | 34 | 50 | 80 | 15.5 |
| HJL553444 | 850 | 3.7 | 5.5 | 34 | 44 | 80 | 15.5 |
| HJL603048 | 850 | 3.7 | 6.0 | 30 | 48 | 80 | 15.5 |
| HJL603843 | 900 | 3.7 | 6.0 | 38 | 43 | 60 | 18 |
| HJL652754 | 900 | 3.7 | 6.5 | 27 | 54 | 60 | 18.1 |
| HJL523450 | 900 | 3.7 | 5.2 | 34 | 50 | 60 | 18.2 |
| HJL573345 | 920 | 3.7 | 5.7 | 33 | 45 | 75 | 19 |
| HJL414551 | 950 | 3.7 | 4.1 | 45 | 51 | 40 | 19.3 |
| HJL653048 | 950 | 3.7 | 6.5 | 30 | 48 | 40 | 19.5 |
| HJL603448 | 950 | 3.7 | 6.0 | 34 | 48 | 40 | 19.6 |
| HJL583450 | 980 | 3.7 | 5.8 | 34 | 50 | 70 | 17.6 |
Notes:
OEM arrangement is welcome and customization for sepcial tooling is also avaliable upon request. Specifications stated above are subject to change without further notice,For more detaild information and avaliability,Pls consult HJL directly.
FAQ
Q1. What is your terms of packing?
----- Normally in neutral plastic box and carton.
Q2. What is the payment terms ?
------T/T,Paypal,Western Union in advance.
Q3. What is your terms of delivery?
----- EXW, FOB,CFR ,CIF,DDP,DDU,and etc.
Q4. How about your delivery time?
-----Generally,10-15 days around for samples,24-30 days around for batch production delivery time.
Q5. Can you produce according to the samples and clients drawing?
-----Yes, we can make samples based on our clinets certain technical drawing,But sample cost need to be taken by clients.
Q6. What is your quality policy?
-----Quality warranty is 12 month,and if there is any defect products on last order,we can replace free new one on next shipment.
Q7. Do you test all your goods before delivery?
---- Yes, Our battery MUST go through 100% test and inspeciton before delivery.
Q8. How do you make our business long-term and good relationship?
-----1. We keep good quality and competitive cost to ensure our customers benefits and success.
-----2. We respect every customer as our friend with win-win relationship,no matter where they come from.
| UN38.3 CERTIFICATION LIST MODEL | |||||||
| Model No | Norminal Capacity | Norminal Voltage | Cell Demensions(mm) | Internal Resistance(omh) | Approximate weight(g) | ||
| Thickness | Width | Height | |||||
| HJL421133 | 125 | 3.7 | 4.2 | 11.5 | 33.5 | 200 | 3.2 |
| HJL382035 | 220 | 3.7 | 3.8 | 20.5 | 35.5 | 180 | 4.8 |
| HJL472228 | 380 | 3.7 | 4.7 | 22.5 | 28.5 | 100 | 7.8 |
| HJL652447 | 700 | 3.7 | 6.5 | 24.5 | 47.5 | 80 | 14 |
| HJL404864 | 1500 | 3.7 | 4.0 | 48.5 | 64.5 | 50 | 32 |
| HJL357390 | 2000 | 3.7 | 3.5 | 73 | 90 | 60 | 39 |
| HJL337095 | 2400 | 3.7 | 3.3 | 70 | 95 | 70 | 46 |
| HJL357390 | 2500 | 3.7 | 3.5 | 73 | 90 | 60 | 50 |
| HJL113465 | 2850 | 3.7 | 11.0 | 34.5 | 65.5 | 60 | 52 |
| HJL357095 | 3000 | 3.7 | 3.5 | 70 | 95 | 50 | 54 |
| HJL545575 | 3000 | 3.7 | 5.4 | 55.5 | 75.5 | 40 | 55 |
| HJL4065130 | 4000 | 3.7 | 4.0 | 65 | 130 | 60 | 77.8 |
High quality 1254 60mah button type lithium battery
