Гравиметрический центробежный концентратор Falcon
- Категория: >>>
- Поставщик: Jiangxi Tongli Mining Machinery Co. Ltd.
Сохранить в закладки 62493506488:
Описание и отзывы
Характеристики
Gravimetric Falcon Centrifugal Concentrator
| Product Description Falcon Centrifugal Concentrator |
Gravimetric Falcon Centrifugal Concentrator
Falcon Centrifugal Concentrator(gold centrifugal concentrator) is a family of Mineral Processing Products specifically designed to recover free gold, which is, the gold that does not require gold cyanidation for recovery.The Centrifugal Separator is a type of gravity concentration apparatus. This Centrifugal Separator use the experience of Knelson and Falcon Concentrator. So far, the Chinese version is with a better price and good efficiency. Centrifugal Concentrator
Technical Specification | |||||
Model | STLB20 | STLB30 | STLB60 | STLB80 | STLB100 |
Capacity (T/H) | 1-3 | 2-7 | 15-30 | 30-70 | 60-100 |
Feeding size (mm) | 0-3 | 0-3 | 0-5 | 0-5 | 0-6 |
Feeding density | <50% | ||||
Fluidization water(m3/H) | 1-2 | 4-6 | 10-20 | 20-35 | 40-60 |
Concentrates weight(kg) | 2-3 | 8-15 | 25-40 | 60-70 | 70-80 |
Water pressure(Mpa) | 0.06-0.1 | 0.1-0.15 | 0.1-0.2 | ||
Motor power(kw) | 0.75 | 1.5 | 4 | 11 | 18.5 |
Dimension(mm) | 800×700×980 | 1050×900×1150 | 1600×1400×1800 | 2100×1800×2100 | 2300×2000×2200 |
Weight (kg) | 270 | 420 | 1600 | 2500 | 3750 |
Gravimetric Falcon Centrifugal Concentrator
| Main Features Falcon Centrifugal Concentrator | |
Only one moving part Low acquisition and operating costs Ease of Installation | With VFD High concentration ratios Low machine weight |
 | |
| STLB20 STLB30 STLB60 STLB80 STLB100 | |
Gold Gold Prospecting Concentrator/Equipment Panning Kit
| Structure Falcon Centrifugal Concentrator |
 | 1. Belt drive 2. Motor 3. Outer shell 4. Feed tube 5. Stainless steel cone bowl 6. Pressure water jacket 7. Tailings outlet 8. Absorber 9. Framework 10. Concentrates outlet 11. Hollow shaft 12. Recoil water inlet |
| Detailed Images Centrifugal Concentrator |
 | Part name: Cone bowl
Brand: Tongli gold separator machine
Origin: China gold panning tray
In standard, the cone bowl is the stainless steel type. The customized material is acceptable, too.
As the most important part of the machine, its price takes a large percentage of the price of the whole machine. |
Part name: Filter of fluidization water
Brand: Tongli gold panning tray
Origin: China
Centrifugal Concentrator The clean water is very important for the concentrator efficiency. The filter is used to prevent the impurities from feeding into the concentrator.
gold centrifugal concentrators |  |
| Part name: Motor
Brand: Tongli gold panning tray
Origin: China copper concentrator
Falcon Centrifugal Concentrator The elec motor is specially for export, with high quality. gold centrifugal concentrators For concentrator with VFD, the motor will be the Variable-Frequency Adjustable-Speed Motor.
gold centrifugal concentrator |
| Gold Gold Prospecting Concentrator/Equipment Panning Kit |
Packaging & Shipping
$t
 | FCL | |
| Size | with 20/40GP container | |
| Weight | Centrifugal Concentrator | |
| Packing details | The machine is usually loaded and fixed in the container mostly assembled.Falcon Centrifugal Concentrator | |
 | LCL $keyword1) | |
| Size | Centrifugal Concentrator | |
| Weight | Centrifugal Concentrator | |
| Packing details | LCL usually refers to the smaller models. The machine is packed inside in steel frame and outside in plywoodGravimetric Falcon Centrifugal Concentrator | |
About Us
Jiangxi Tongli Mining Machinery Manufacturing Co., Ltd is a company who specially supplies mining equipment for export, layout design, plant installation & debugging, and technical support. With more than 15 years' manufacturing experiences, our customers and services have covered more than 50 countries all over the world .
--- PRE-SALE SERVICE ---
1.Based on clients’ request and budget, TONGLI experts will strictly make efficient, reliable solutions accordingly;
2.Mine sample testing is available, we welcome the customer send the sample to you for testing by courier, or, the customer take the sample to our factory for testing;
3. Design and provide the complete processing flowchart;
4. Design & manufacturer products according to clients’ demands.
--- AFTER-SALE SERVICE ---
1.Pre-check and test the products before delivery;
2.Deliver the whole plant design for our clients which including infrastructure, electrical system and pipeline system design;
3.Trace the status of the shipping until the products received;
4.Prepare required documents to let clients pass custom clearance;
5.Dispatch experts to carry out below service on site: 1) Installation & debug of the machinery 2) Train the first-line operators & technical personnel
3) Carry out any other service clients may need
6. Provide technical exchanging & spare parts for life-long term
--- ONE STOP SOLUTION ---
1.Starting by running the mineral beneficiation experiment. To provide our clients with the best solution accordingly;
2.Besides supply the flowchart design & equipment, we also provide the infrastructure design; Electrical & pipeline system design, etc. To help our clients complete the design of the whole plant;
3.After the installation, debugging of the equipment, the official production will also be guiding by our experienced engineers on site, to guarantee the output minerals perfectly meet your demands.
1. Are you a trade company or a manufacturer?
A: We are an ISO9001:2008 and CE verified manufacturer specialized in various kinds of mining equipment as well as mining technology. OEM & ODM service are available.
2. What is your delivery time?
A: The delivery time is about 7-20 days after receipt of payment.
3. What is the payment terms?
A: The payment term is 45% payment in advance, 55% balance before shipment.
4. Why choose you as supplier?
1). High quality & most competitive price
We are a factory who could provide the lowest price to you.
We are more than 20 years experiences in mining equipment.
2). Fast delivery--Goods will be shipped within 7 - 30 days based on order quantity.
3). Best service--Overseas customers can enjoy 24/7 after-sale service and dispatching service
4). 3D & CAD flow chart design
Welcome to sent inquiry and welcome to visit our factory!
Back to Homepage
Gravimetric Falcon Centrifugal Concentrator
Gravimetric Falcon Centrifugal Concentrator
