CE and UL certificate approved ho7rn-f and sjow rubber insulated cable specification and price.jpg






Product Description


600V 3x14AWG 16AWG 18AWG 12AWG SJOOW Cable with UL certificate




 Application:


Type SOOW Flexible Cords are permitted for use by Article 400 and related articles of the National Electrical Code. SOOW cords are designed for extra hard usage on industrial equipment, heavy tools, battery chargers, portable lights and power extensions. They are sunlight, water, oil and weather resistant and suitable for outdoor applications.





Specifications:


• Conductors: Fully annealed, stranded bare copper, per ASTM B-174, sizes 18 - 2AWG


• Insulation: EPR insulated


• Jacket: CPE sheathed


• Temperature Rating: -25°C to + 90°C


• Water resistant and an oil resistant jacket


• Lightweight and Very good flexibility


• UL Flexible Cord Subject 62


• FT1 and FT2 Flame Test


• Sunlight Resistant


•CUL Listed


Option:


Temperature Rating  -40°C- 105°C





 Construction:


Type SOOW Flexible Cords are manufactured using bare flexible stranded Class K copper conductors, with a heat, moisture and oil resistant EPDM rubber insulation. The insulated conductors are cabled with wax paper fillers. A tissue-paper separator is wrapped around the assembly to promote easy removal of the jacket. A heat, moisture and oil resistant flexible CPE jacket is extruded over the assembly to complete the construction
















SOOW Cable.JPG



Packaging & Shipping


Standard export drum,500meters/rdum,1000meters/drum or as your requirment.


888888





Certifications


We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At thte same time, we have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificate





USA is our main market. We have many distributors from USA companies. And we have obtained UL certifications for many products, such as TC cable, DLO cable,RHH/RHW/RHW-2/XHH/XHHW/XHHW-2/SIS, THHN/THHW/THW/THW-2/THWN/THWN-2/TW,SER/SEU/USE/USE-2/MHF, MV-90/MV-105,TC cable,MC cable,DLO,type DG,PV wire,AC Cable,Soow,Welding cable  and so on.


UL certificate.jpg





Company Information


 Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billionYuan.Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, largescale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria,Congo, Middle East and Southeast Asia and so on.


office





laboratory


Our laboratory center are authorized by both of ILAC (International Laboratory Accreditation Cooperation)&CNAS(China National Accreditation Service for Conformity Assessment), so the testing results in our labs can be accepted by the international countries belong to the above organizations.


initpintu_initpintu_





FAQ


1.How many year have our factory producing power cable?


Our factory produce power cable for 22 years.


2 Hong Long time the customer can get the new price after get your inquiry?


 Usually , It is only one hour is ok for us , because we are factory , we caculate the price by ourself.


3.Which port our factory is near to?   Tianjin port


4.Which payment term do we accept?


 T/T 30% in advance and balance before shiping the product or L/C 100% at sight both is ok.


5.What about the package for our power cable?


 It is usually packed in strong wooden drum.The drum size is usually:2.0m x 1.25m x 1.12m x 1.4m which suitable for container , we can do it according to customer requirments.


6.How long meter power cable for one wooden drum?


  This is according to power cable's diameter and customer's requirments.


7.How about our delivery time?


  According to your order's quantity , for 1million meters power cable, it is only 25 working days is ok.


8.Do we provide sample for free?


  Yes , we provide the sample to you for free , you only paid for the delivery freight is ok.





contact information




Frank Wang :Sales Engineer


Hebei Huatong Wires&Cables Group Co.,Ltd.


The largest wires and cables manufacture and exporter in whole China.





Send me a message here, you will get best offer within 6 hours!
