Wiegand66 to TCP/IP Network RJ46 Port double -way transmission converter for turnstile access system use

Product Description

Standard Wiegand communication converter is designed for transfer Wiegand data (26bit

34bit,37bits) with other device which have Wiegand input interface. It mainly use for hand-held testin

tool or embedding into products manufactured by third-parties, especially for our RFID an

access control system solution.

The converter support double-way transmission, can transfer Wiegand 26bit Wiegand

34bit or wiegand37bit data to TCP/IP data, also can transfer data via TCP/IP interface to Wiegand 26bit

Wiegand 34bit data.

Standard Wiegand output 26bit data in default (Wiegand 34bit and other format as optional

standard TCP/IP output ASCII number (hex format as optional) with communication protoc

based on 9600,N,8,1 standard.

Technical Specification

Size: 90mm x 45mm x 35mm

Net Weight: 0.1KG

Operating voltage: DC 9V-12V;

Baud rate: 9600 (N, 8, 1)

Network interface: Super port USR-K2 Ethernet RJ45 port (it adopt 10M/100M self-adaption

interface, support AUTO MDI/MDIX,support 2KV Electromagnetic isolation)

Network protocol: support Ethernet, ARP, IP, UDP, TCP, etc.

Working Temperature: -25~75℃

Storage Temperature: -40~105℃

Storage Humidity: 5%~95% RH

Input:2 channel wiegand input,can connect LED Indicator and Buzzer

For TCP/IP (RJ45) interface:  it adopt 10M/100M self-adaption interface,

support AUTO MDI/MDIX, so you can connect the converter with your

computer direction, and also can testing direct. Here is the detail definition:

Module Appearance:

Refer to the picture, you can check the appearance and size:

Software and testing

We can provide testing software, please download from our website:

Here is the screen copy of the testing software:

The default parameter of the device had set as the screen picture.

Any more questions, please contact us by email for get more support!

Product Appearance for reference:
