Product Description
PUR features are excellent adhesion, can laminate 99.9% fabrics, it is non-toxic and environmental ,the laminated fabrics’ adhesion and flexibility are very good, the fabrics are high temperature resistant, low temperature resistance to fracture,moisture not easily affected by the temperature after reaction, flexible durable, wear-resisting, oil resistant, anti-aging. It is replacing traditional solvent and water-based rubber joint, besides PUR has excellent mist effectiveness, low precipitation material and neutral color features, it can be applied to must repeat disinfection of medical products.
Feature
1. Because getting hot melt adhesive in PUR, with a few evenly coating weight can get washable and solvent resistance fabric
2. The hot melt adhesive no solvents, it is an a natural green glue.
3. Hot melt adhesive doesn’t contain water so no need to dry, the laminating speed is very fast.
4. The lamination process is humid solid state reaction, irreversible, laminating the fabrics firmly and washable.
5. Strong glutinosity, saving glue consumption, saving production cost.
6. Lamination process fully linkage control, base fabrics no stretching, light in weight, soft, good handle.
7. The heating source is from oil heating, quick heating, the heat is evenly.
8. Melting adhesive system is independent, melting adhesive fully and quickly.
9. Point-like anilox gluing method, the finish fabric has good air permeability and strong third dimensional.
10. Garment fabric and shoes fabric laminate with PTFE, TPU, PE film, fabric laminate with fabric.
1. Because getting hot melt adhesive in PUR, with a few evenly coating weight can get washable and solvent resistance fabric
2. The hot melt adhesive no solvents, it is an a natural green glue.
3. Hot melt adhesive doesn’t contain water so no need to dry, the laminating speed is very fast.
4. The lamination process is humid solid state reaction, irreversible, laminating the fabrics firmly and washable.
5. Strong glutinosity, saving glue consumption, saving production cost.
6. Lamination process fully linkage control, base fabrics no stretching, light in weight, soft, good handle.
7. The heating source is from oil heating, quick heating, the heat is evenly.
8. Melting adhesive system is independent, melting adhesive fully and quickly.
9. Point-like anilox gluing method, the finish fabric has good air permeability and strong third dimensional.
10. Garment fabric and shoes fabric laminate with PTFE, TPU, PE film, fabric laminate with fabric.
In industrial use, hot melt adhesives provide several advantages over solventbased adhesives. Volatile organic compounds are reduced or eliminated, and the drying or curing step is eliminated. Hot melt ad-hesives have long shelf life and usually can be disposed of without special precautions.
The most advanced hot melt adhesive, moisture reactive hot melt glue (PUR & TPU), is highly adhesive and environmentally friendly. It can be used for lamination of 99.9% textiles. The laminated material is soft and high temperature resistant. After moisture reaction, the material will not be easily affected by the temperature. Besides, with lasting elasticity, the laminated material is wear resistant, oil resistant and ag-ing resistant. Especially, mist performance, neutral color and other various features of PUR makes medi-cal industry application possible.
When PTFE, PE, TPU and other functional waterproof and breathable films are used in laminating, water-proof and heat preserving, waterproof and protective, oil & water & gas filteration and many other different new materials will be created. The demands of garment industry, motor manufacturing, medical industry,environment protection industry will be met.
Our hot melt laminating machine is mainly consisted of fabric rewinding and unwinding units, fabric and film transmission systems and tension controller, film unwinding and lining or film carrier rewinding device, hot melt glue melting unit (optional), pump (optional), conduction oil source system (optional), glue dot transfer unit, laminating device, cooling device, PLC and other devices. It is compact, highly automatic and easy to maintain.
The most advanced hot melt adhesive, moisture reactive hot melt glue (PUR & TPU), is highly adhesive and environmentally friendly. It can be used for lamination of 99.9% textiles. The laminated material is soft and high temperature resistant. After moisture reaction, the material will not be easily affected by the temperature. Besides, with lasting elasticity, the laminated material is wear resistant, oil resistant and ag-ing resistant. Especially, mist performance, neutral color and other various features of PUR makes medi-cal industry application possible.
When PTFE, PE, TPU and other functional waterproof and breathable films are used in laminating, water-proof and heat preserving, waterproof and protective, oil & water & gas filteration and many other different new materials will be created. The demands of garment industry, motor manufacturing, medical industry,environment protection industry will be met.
Our hot melt laminating machine is mainly consisted of fabric rewinding and unwinding units, fabric and film transmission systems and tension controller, film unwinding and lining or film carrier rewinding device, hot melt glue melting unit (optional), pump (optional), conduction oil source system (optional), glue dot transfer unit, laminating device, cooling device, PLC and other devices. It is compact, highly automatic and easy to maintain.
Laminating Machine for :
2. EVA + Fabric (for shoe materials, etc)
3. Neoprene + Fabric (for diving suit, etc)
4. PU Foam + Fabric (for bra, vehicle cushion, etc)
5. TPU Film + Fabric. (for climbing clothing, camouflage uniform, etc)
6. Fabric + Fabric. (for clothing, medical supplies, etc)
Detailed Images
Size Information
Electric Heating Tube | 60KW |
Voltage | 380V 50HZ |
Max Coating Speed | 40m / min |
Working Width | 1800mm |
Size(L×W×H)(mm | 12*3.4*3.4meters |
Package Dimension | One 40GP Container |
Related Products
Packing&Shipping
Company Introduction
FAQ
1. Established time?
Ponse was established for 20 years, specialized in laminating machine, cutting machine and embossing machine.
2. Warranty period?
One year.
3. How to choose right laminating machine?
Please let us know as below:
1 which material to laminate
2 what is final usage
3 what is max width for your material roll
4. Installing and operating?
Our Professional people will go for installing and offer the technical guidance as requests.
5. How many staff for operating of the machine?
3 to 4 workers
6. Voltage requirements?
According to different voltages in various countries, to be customized.
7. Payment Terms?
FOB, CIF, CNF or Ex-work; payment way: T/T or L/C.
8.Delivery method?
Shipping by sea. Shanghai Port to destination country.
Ponse was established for 20 years, specialized in laminating machine, cutting machine and embossing machine.
2. Warranty period?
One year.
3. How to choose right laminating machine?
Please let us know as below:
1 which material to laminate
2 what is final usage
3 what is max width for your material roll
4. Installing and operating?
Our Professional people will go for installing and offer the technical guidance as requests.
5. How many staff for operating of the machine?
3 to 4 workers
6. Voltage requirements?
According to different voltages in various countries, to be customized.
7. Payment Terms?
FOB, CIF, CNF or Ex-work; payment way: T/T or L/C.
8.Delivery method?
Shipping by sea. Shanghai Port to destination country.
