Light steel villa, also known as light steel structure housing, its main material is by hot dip galvanized steel strip by cold rolling technology synthesis of light steel keel, after accurate calculation plus auxiliary support and combination, play a reasonable bearing capacity, to replace the traditional housing.
Assembly method | assembled | ||||
Use | living in a family, hotel, supermarket, etc | ||||
Size | Custom | ||||
Modeling | Customization | ||||
Color | Custom | ||||
Function | Residence | ||||
Structure | Light steel structure keel: G550 Z275 Australian standard keel thickness 0.8 | ||||
Exterior wall structure | 12mm OSB board |
1. Main structure, containing light steel structure with thickness 100mm fiber glass wool.
2. Roof cover, containing thickness 12mm OSB board + thickness 3mm waterproof tar paper + asphalt shingle. 3. External wall,
containing thickness 9mm OSB board + one-way breathing paper. 4. Internal wall, containing thickness 8mm calcium silicate plate.
5. Roof ceiling, containing thickness 8mm calcium silicate plate. 6. Ground of second storey and stair, thickness 18mm OSB board +
thickness 3mm waterproof tar paper. 7. Decoration for external wall, containing thickness 8mm fiber cement plate or thickness 15mm
engraved metal board or artificial stone paint. 8. Decoration for internal wall, containing thickness 9mm bamboo wood fiberboard
or tile or latex painting. 9. Decoration for roof ceiling, containing thickness 9mm bamboo wood fiberboard or latex painting. 10.
Decoration for second storey ground and stair, tile or wooden floor. 11. Entrance gate, inside doors and all windows. 12. Brand
wire and tube.
