1055 Carbon Steel,Din 1.1730 Steel,S50C Mould Steel

1. Chemical composition

C	Si	Mn	P	S	Cu
0.47-0.53	0.15-0.35	0.60-0.90	≤0.035	≤0.035	≤0.25
Cr	Mo	Ni	V	W	Co
≤0.25	-	≤0.30	-	-	-

2. Equivalent Steel Grade

DIN	ASTM	GB	EN / ISO	JIS	BS
1.1210	1050	50	C50E4	S50C	060A52

3. Mechanical Properties

Tensile

Strength

(MPA)

Yield Strength

(MPA)

Elongation

(%)

Reduction

(%)

Impact

(Aku/J)

Condition

630

375

Normalized

Hardness: Annealed ≤207HB, Cold drawn ≤235HB.

4. Charateristics

The properties of SAE-AISI 1050 steel include three common variations. The property values on this page show ranges across all of them. For more specific values, follow the links immediately below. The graph bars on the material properties cards further below compare SAE-AISI 1050 steel to: wrought plain carbon steels (top), all iron alloys (middle), and the entire database (bottom).

5. Applications

This grade of steel is used for the manufacture of blades, brackets, brake discs, clips, clutches, springs, washers and gears and for a wide range of applications that can make use of its good combination of mechanical properties.

Application

_01

AVAILABLE PRODUCTS

STEEL TYPE	GB	AISI/ASTM	DIN	JIS	EN
COLD WORK MOLD STEEL	Cr12	D3	1.2080	SKD1	X210Cr12
	Cr12MoV	D3	1.2601	SKD11	X165CrMoV12
	Cr12Mo1V1	D2	1.2379	SKD10	X153CrMoV12
	9CrWMn	O1	1.2510	SKS3
HOT WORK MOLD STEEL	4Cr5MoSiV1	H13	1.2344	SKD61
HOT WORK MOLD STEEL	4Cr5MosSiV	H11	1.2343	SKD6
PLASTIC MOLD STEEL	3Cr2Mo	P20	1.2311	SCM4
	3Cr2MnS	P20+S	1.2312
	3Cr2NiMo	P20+Ni	1.2738
	4Cr13	420	1.2083	SUS420J2
	4Cr16	420	1.2316	SUS420
	2Cr13	420	1.4021	SUS420J1
HIGH SPEED STEEL	CW6Mo5Cr4V2	M2	1.3342
HIGH SPEED STEEL	W6Mo5Cr4V2	M2	1.3343	SKH51
ALLOY STRUCTUAL STEEL	40Cr	5140	1.7035	SCr440
	42CrMo	4140	1.7225	SCM440
	40CrNiMoA	4340	1.6511	SCM439
	40CrNiMoA	4340	1.6582
	20CrNiMo	8620	1.6523
	20CrMn	5120	1.7147
	GCr15		1.3505
	50CrV	6150	1.8159
CARBON STRUCTUAL STEEL	45	1045	1.1191	S45C

Advantages

_02

_03

About us

About us

Dongguan Songshun Mould Steel Co.,Ltd.is located in Chang'an Town -the famous town of
mold in Pearl River Delta of China.After 15 years' development,now we have the capacity to
provide complete services from manufacturing and marketing to distributing.The main grades
of tool steel and special steel which we market are listed as follows:

Hot work steel:H13,H21,1.2714,etc.
Cold work steel:D2,D3,D6,01,A2,etc
Plastic Mould Steel:P20,1.2738,1.2083,1.2767,1.2312,1.2316 etc.
HSS:M2,M35,M42,etc.
Alloy Steel:4140,42CrMo4,4130,4340,8620,5140,5160,6150,4135,52100,etc
Carbon Steel:Q235,Q345,1045,1084,etc

As a large-scale wholesaler and retailer,we have the excellent service organization and
first-class marketing personnel.We have been specialized in domestic and overseas markets
for many years,and have established qood and stable business relationships with many overseas clients.

Because of our high-quality products,timely delivery,competitive price and good service,we have won high praises from all our customers.

We always insist on the idea of "The quality is first,the is supreme",and inherit the principle of \\"equality,equity and reciprocity".We sincerely hope to cooperate withmore importers,and make
progress together.
