Product Description


  Digital Schmidt Concrete Test Hammer, impact test hammer




HT-225D is an integrated digital concrete test hammer which combines data processor and test hammer into one unit. It is widely used for non destructive testing quality of concrete and building materials in finished structure or prefabricated blocks. From its rebound value, the compressive strength of concrete can be calculated out automatically. All testing data can be stored in memory and transferred to PC by USB cable or wireless by Blue tooth.





Features:


ü  High contrast OLED display


ü  All setup can be made on site


ü  Automatic calculating compressive strength


ü  Automatic correction of impact direction


ü  All data will be stored in memory


ü  All data can be transferred to PC by USB cable or blue tooth(optional)


ü  Dual display for analogue ruler and digital value





Parameter


Display: OLED digital


Measuring range: 10-70N/mm2


Impact energy: HT-225D: 0.225kgm (2.207Nm), for testing ordinary building and bridge construction


       HT-75D: 0.075kgm (0.735Nm), for testing small and impact-sensitive parts of concrete or artificial brick


       HT-20D: 0.020kgm (0.196Nm), for testing mortal or clay of products


Accuracy: ±0.1R


Communication: USB2.0 or Blue tooth (optional)


Memory capacity: data for 4000 concrete structures


Operating temperature: -40º~60ºC


Power: 3.7V Li-ion rechargeable battery charged via USB port


Dimension: 280x75x60mm


Weight: 1kg





Conform to EN12 5042-, ENV 206, DIN 1048, ASTM C805/D5873





HT-225D concrete test hammer_HT-225DHT-225D
