Экспорт китай тяжелый автомобиль HOWO полноприводный

CHASSIS Model No:

HW7/380/K38/6*6W

Gross weight  (kg)

25000

curb weight    (kg)

12490

Rated load quality  (kg)

11880

Max. Speed  (Km/h)

76

Cab

HW76 long cab with Super-large LCD screen,one sleeper , large area of windshield glass, air conditioner, heating system, adjustable seat, two-speed wiper and glass washer, sun visor, safety belts, adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers with transverse stabilizer.

Engine

Make:  SINOTRUK

Diesel:  4-stroke direct injection diesel engine

Engine model : WD615.96C ,EURIII emission standard,6-cylinder in-line with water cooling ,turbo-charging and intercooling

Engine power :380

Displacement :  9.726L

Transmission

HW19710  SINOTRUK 10 forward & 2reverse

Ratio:14.28

Torque 1900Nm

clutch

SINOTRUK Φ430 A size clutch

Driving Axle

ST16 welded high strengthen heavy duty axle

Rated loading capacity: 16T/axle

Ratio:5.73.

Optional: 6.72 for bad road conditions

Front axle

STR

cast steel steering axle with big Nuclearance and light weight

Transfer case

Model: ZQC2000

High-grade / low-grade ratio:0.89/1.536

Braking system

Service brake: dual circuit compressed air brake

Parking brake: spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust brake

Option:ABS

Electrical System

Operating voltage:24V, negative grounded

Steering

ZF8098 German Hydraulic steering with powder assistance

Wheel & Tyres

12.00-20 Bias tires

Optional: 12.00R20 Radial tires

No.of Tyres:10+1

No. of Spring leaf

9/12

Front/ Rear axles loading capacity (kg)

7000/18000

No. of axles

3

Wheel base

3800+1400

Front/ Rear wheel track

2022/1830 mm

Front/Rear hanging

1578/2090 mm

Approach/ Departure angle (°)

31 /18

Dimensions(L*W*H) (mm)

8868×2496×3180

Van dimension  (mm)

6100*2326*600
