Полуавтоматическая резиновая Порошковая линия шин для легковых автомобилей XKP560

Описание и отзывы

Характеристики

waste tire recycle machine /rubber powder machine/rubber powder production line

1.rollers are chilled cast iron
2.harden tooth reducer;bear bush
3.30-120 mesh
3.CE/SGS/ISO

1.Process flow

tire ring cutter → steel wire extractor→ tire shredder→ rubber coarse crusher→ magnetic separator→ vibrating screen1→ fine rubber crusher→ vibrating screen2 → cyclone classifier→ storage bin→ rubber grinder →vibrating screen3→package

2.This production line including the below

1. ring cutter

This machine mainly used to cut the sidewall of steel wire tire, and then to the next step of segmentation. First, put the tire on the platform, then rotate the hand wheel, the three claws will stick the inner tire firmly. Second, Starting power. Work platform will rotation, cutting tool according to need to cut tire slowly, step by step, until the tire side cut off.

2.strips cutter

 strips cutting machine can cut cycle machine to remove the wire tire sidewall cut into strips ,and the width of the adjustable section .Two circular knives for special materials ,hard and durable , can be used repeatedly grinding for no more than 1200 steel tires.

3.Block cutter

 Block cutter is designed to cut car, truck and rear tractor tire. range is up to 120cm truck tires. the tire cutter adds flexibility to your total tire cutting system by providing you the opportunities of accepting tires up to 120cm into your system ,The unit also allows your system to cut 60-70 truck tires per hour or 120-150 car tires per hour.

4.Bead wire separation

 Be utilized to separate rubber and steel wire of bead in order to get whole steel wire .

Feature:It is easy operation ,easy to be installed and maintained high efficiency and clean etc.

5.Tyre crusher

This machine is mainly used to crush waste tire and rubber .the structure is gear transmission

100% Real Manufacturer,

Welcome to visit our factory and we can show you the machine in working condition:

If our products win your interest, please send us inquires with detailed requirement and we will provide detailed information to you. We can also make machines according to your request.
