TalkPod TP UV5 двухдиапазонный двухсторонняя радиоустановка автоматические промышленные идентификации ani код

Описание и отзывы

Характеристики

Dual-Frequency, Dula-Display & Dula-Standby
Vibrating alert function
Two lines dot-martrix display
Automatic Numbering Identification (ANI) code
Built-in Voice Operarte Transmit (VOX) function
CTCSS and DCS/5 Tone/MSK/DTMF encoder
Scan Function & Scrambler
Three color LCD backlight adjustable
Emergency alarm
Built-in FM radio receiver

The Vibrating Alert Function
TP-UV5 has a unique vibrating alert function, prompt transceiver is receiving commands in noisy environments.
Ergonomic Design and Compact Body
With beautiful ergonomic design, TP-UV5 has a lightweight and compact body, which makes it strong and durable.
Three color LCD backlight adjustable
TP-UV5 has LCD display with blue, purple, orange tri-color adjustable background light.
Hang Up Prompt
When you finish your words, the two-way radio will send "tick" to prompt.
Superior, Stylish and Eye-catching Appearance
With human-computer interaction design concept, its superior, stylish and eye-catching appearance make people too hard to put it down.
Automatically Eliminate Noise
When you are stay in noisy environment, it is hard for you to hear clearly. But TP-UV5 can eliminate the noise automatically, so that you can hear what others say.
Voice Operated Transmit (VOX)
Enjoy the convenience of hands-free operation when used with optional accessories.
Time-out Timer
The feature allows for more efficient use of channels by limiting the amount of time of each transmission.
Super Penetrability
A powerful speaker ensures clear, crisp and strong penetrability, even in noisy environments. Even if you are in lift, basement or building, the TP-UV5 will bring you prompt and reliable communication.
High-Quality Sound Against The Tumult
In a noisy environment, the Two-way radio can automatically adjust to filter the ambient noise, and allows users to receive high-definition signal.
Monitor
Allows users to monitor the activity on the current channel. The feature is especially helpful for receiving a weak signal.

General Specifications
Model Number TP-UV5
Frequency Range VHF:136-174MHz & UHF:400-470MHz
Channel Capacity 128
Channel Spacing 5/6.25/10/12.5/25/37.5/50/100KHz
Operating Voltage 7.4V DC
Battery 2000mAh Li-Ion Battery
Battery Life (5-5-90 Duty Cycle) 14 hours
Operate Mode: Simplex or Semi-duplex
Operating Temperature -20°C~+50°C
Antenna Impedance 50Ω
Dimensions (H×W×D)
(with battery, without antenna) 115mm×57mm×32mm
Weight (with antenna & battery) 220g
Transmitter
RF Power Output UHF:4.2±0.5W VHF: 4.8±0.5W
Frequency Stability ±2.5 ppm
Spurious Radiation ≤7.5uW
Adjacent Channel Power ≥65dB
Max Frequency Deviation ≤5KHz
Audio Distortion ≤5%
Modulation Character +3dB ~ -3dB
Occupied Bandwith ≤16KHz
Receiver
RF Sensitivity <0.20μV
Adjacent Channel Sensitivity ≥55dB
Audio Response +2dB ~ -10dB
Co-channel Selectivity ≥ -8dB
Audio Distortion ≤5%
Intermediation Rejection ≥55dB
Blocking ≥85dB
* Specifications subject to change without notice.
