Безвентиляторный Core i3 5005U/ Core i5 5200U/ Core i7 5500U CPU, прочный корпус из алюминиевого сплава промышленный Мини ПК
Безвентиляторный Core i3-5005U/ Core i5-5200U/ Core i7-5500U CPU, прочный корпус из алюминиевого сплава промышленный Мини ПК
Безвентиляторный Core i3-5005U/ Core i5-5200U/ Core i7-5500U CPU, прочный корпус из алюминиевого сплава промышленный Мини ПК
Безвентиляторный Core i3-5005U/ Core i5-5200U/ Core i7-5500U CPU, прочный корпус из алюминиевого сплава промышленный Мини ПК
Безвентиляторный Core i3-5005U/ Core i5-5200U/ Core i7-5500U CPU, прочный корпус из алюминиевого сплава промышленный Мини ПК

Безвентиляторный Core i3 5005U/ Core i5 5200U/ Core i7 5500U CPU, прочный корпус из алюминиевого сплава промышленный Мини ПК

Share on (10000002256476):


Price:

Quantity:


Product Overview

Description





Features\t\t\t\t

• Intel® Core Core i3-4010U/ i5-4200U / i7-4500U Processor)
• One channel 2GB/4GB/8GB/ DDR3L 1333/1600MhzMax to 8GB
• Support 2x RJ45 10/100/1000Mbps Intel 8111F Gigabits Ethernet
• With 4 x USB3.0 / 4 x USB2.0
• Support 6 x RS232 COM
• Support Dual Display VGA+HDMI
• Support WiFi module with dual antenna,300M,802.11.b/g/n
• OS Support: Win 7/ Win 8/ Win 10/ Linux etc.
• With Fanless, Low power consumption




COM
Support 6 x RS232
Display Port
Support Dual Display VGA+HDMI
LAN
2x RJ45
USB
4 x USB3.0 / 2 x USB2.0
Operation System
Support Win 7/ Win 8/ Win 10/ Linux etc.
size
180*128*55mm
colour
BLACK
Product Features
With Fanless, Low power consumption
Material
Aluminum Alloy
Selling Units
Single Unit
Single package size
290*260*170mm
Single gross weight
2.5KG


Model Number: UMSM301-G


Main System
CPU
Intel Core i3-4010U
Intel Core  i5-4200U
Intel Core 4500U
Memory
2GB DDR3 (4GB,8GB optional)
Hard Drive Capacity
64G SSD
Hard Drive Optional
SSD: 32GB,128GB,256GB
HDD: 160GB,320GB,500GB,1TB
Graphics
CPU Integrated graphics HD Graphics and support 1080p HD photo quality
Front-Panel Connectors
Power on/off
4 x USB 3.0
2 x RS232/COM
Rear-Panel Connectors
1 x HDMI + 1 x VGA
2 x LAN RJ45 10/100/1000 Mbps Adaptive
1 x DC IN 12V
1 x Audio
2 x WIFI antennas connectors
Ethernet port
2x RJ45 10/100/1000Mbps Intel 8111F Gigabits Ethernet
Wireless Network
with dual antenna,300M,802.11.b/g/n
Operation System
Support Windows 7/8/10, Linux, Ubuntu, Debian etc.
Power Supply
External Power Supply
AC 100 - 240V
Working voltage
DC 12V
Power consumption
≤45W
Enclosure
Material
Aluminum Alloy
Cooling System
Fanless Passive cooling with Heat Sink Aluminum Block
Operating Environment
Temperature Range
operating: -20 to 65°C, storage :-20 to 80°C
Relative humidity
10%~90% @ 40° C, non-condensing
Vibration
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Packing Details
Net weight
1.5KG
Gross weight
2.5KG
Product Dimension
180*128*55mm
Packing size
290* 260* 170mm
Accessories
1x Box PC, 1x Power Adapter, 1x WIFI Module with Dual antennas, 1x User Manual
Other
Warranty
1 year warranty










( BIS ) Beyond Info System emerged from the idea of ( SPEC )
Serving, Protecting, Entertaining, Connecting people. Our main purpose is to serve worldwide customers to provide global village living environment life easier, safer and happier. BIS have extensive experience and professional research with development team specializes in the design and manufacturing industrial PC products as Multimedia AIO System, Embedded Box PC, AIO Touch Panel PC/Monitor, Service KIOSK. BIS allies with local partners to promote various products as we believed local people whom do local business is the best for end users. Asides from developing hardware for ODM/OEM and system integrators worldwide, we are also expertise in electronics parts which able to assist you to source for proper supplement. Please empower BIS to bring benefits to your business, we truly believe you would be satisfied by our passion, efficiency, competitive and services.








1.All in One system Pioneer: BIS is a high-tech enterprise specializing in research, development & Manufacturer of modern education equipments and multimedia product series. With intensive investment and a professional research and development team, we have obtained the leading position in All in One PC industrial sector in Taiwan & China and become one of the best suppliers in this field around the world.

2.Streamlined production: From design, production to after-sales service, the comprehensive and complete integration brings customers high quality service and products. The System test confirms functionality of all systems before packing. We’ve created appropriate programs to ensure quality in all functions of systems. All defective systems are screened at system test then re-run after repair.

3.Core value: With BIS you will enjoy One Stop Service
Our principal of working attitude is to support our partners to solve their matters, we provide “One Stop Service” philosophy from initiate design, implement manufacture, quality control and cost reduction. We are also expertise in electronics parts which able to assist you to source for proper supplement and manage to resell your excess inventory.
