Polypropylene Ground Workshop 1720*1120*1000 mm OPP 11,0 750 (3 liters/sec) Grease Trap For Restaurants / Food Industries
- Category: Water Treatment Machinery >>>
- Supplier: StroiSnabResurs LLC
Share on (10000002816321):
Product Overview
Description
Product Description
Industrial (shop) grease trap for sewerage, exclusively for ground installation (inside technical premises). Fat traps for sewage OPP 11,0-750 are successfully operated in cosmetic, dairy, meat and other food industries-wherever the work is somehow connected with the processing of fat products of any origin and the volume of production effluents does not exceed 3 liters/s (11 cubic meters per hour)
Grease trap for sewage-why is it?
Any grease trap, being an independent treatment unit, serves one purpose - wastewater treatment from the fat products contained in them before being discharged into the general sewer.
The installation of grease separators for sewage is caused by two factors:
- The need to clean industrial effluents from the fat products contained in them, in order to avoid stopping the operation of the internal sewerage of the building.
- The need to comply with the MPC standards of pollutants in the composition of wastewater, in order to avoid sanctions of supervisory authorities (vodokanal, rospotrebradzor, etc.)
The grease trap for sewage OPP 11.0-750 successfully solves both problems, provided that the volume of wastewater entering the sewer network is not more than 3 liters/s.
According to the results of tests of grease traps for sewerage of this series, the following results were obtained:
Indicator | The maximum permissible input concentration is not more than, mg/l | Final concentration, mg/l |
Fat products | 4200,00 | 23,12 |
Connecting the grease trap to the existing sewer system:
The simplicity of the design of the grease trap also ensures ease of installation. Conditionally, the installation of a grease trap is reduced to several simple actions:- Choose a place for installation (taking into account the convenience of future maintenance)
- Cut the existing sewer pipe at the place where the grease trap is connected
- To connect the grease trap to the sewer by means of inlet and outlet pipes
- Fill the grease trap with clean water
Maintenance of grease traps for sewerage of the OPP series-shop
Maintenance (cleaning) of shop grease traps consists in the periodic removal of accumulated fat products from the water surface in both chambers. Occasionally (conditionally - once every six months), a complete cleaning of the grease trap is required to remove bottom sediments (waste) accumulated during the operation of the grease trap.
Cleaning of the grease trap for sewage OPP 11,0-750 can be done manually, or with the use of an ilosos. Special waste disposal services clean the grease traps using vacuum pumps.
In addition, there is a possibility of biological purification of grease traps for sewage with the use of drugs (bacterial complexes) that effectively destroy fats and all kinds of bottom sediments.
How to buy a grease trap for sewage OPP 11,0-750 ?
You can buy or order the delivery of a workshop grease trap for sewage by sending a message to email - sale@ecoseti.ru, or by calling the toll-free number - 8 800 775 2886
Do you still have any questions? Ask them to our specialist, we will help you in the shortest possible time to deal with the selection of a grease trap for sewage in your cafe or restaurant and arrange fast delivery of a grease separator to any corner of Russia
Additional information about the grease trap for sewage OPP 11,0-750:
It is used in large catering enterprises, or in food production, to prepare wastewater for discharge into the city sewer network. Cleaning of the grease separator can be carried out both manually and with an ilosos. The maximum capacity of the grease trap is up to 3 l / s
The grease separator is made of high-quality Czech polypropylene with UV stabilization. The body of the grease trap along the perimeter is reinforced with profile steel pipes. Additional stiffeners are provided along the upper inner perimeter. The housing of exceptional strength allows for underground installation, but it is recommended for internal installation.
The service life of the equipment is more than 25 years. No maintenance is required, except for periodic cleaning of the grease trap.
With properly selected performance, it is necessary to clean such fat traps no more than once every 3-6 months, and when using specialized biological products-no more than once a year.
You can buy or order the delivery of a workshop grease trap for sewage by sending a message to email - sale@ecoseti.ru, or by calling the toll-free number - 8 800 775 2886
Do you still have any questions? Ask them to our specialist, we will help you in the shortest possible time to deal with the selection of a grease trap for sewage in your cafe or restaurant and arrange fast delivery of a grease separator to any corner of Russia
Additional information about the grease trap for sewage OPP 11,0-750:
It is used in large catering enterprises, or in food production, to prepare wastewater for discharge into the city sewer network. Cleaning of the grease separator can be carried out both manually and with an ilosos. The maximum capacity of the grease trap is up to 3 l / s
The grease separator is made of high-quality Czech polypropylene with UV stabilization. The body of the grease trap along the perimeter is reinforced with profile steel pipes. Additional stiffeners are provided along the upper inner perimeter. The housing of exceptional strength allows for underground installation, but it is recommended for internal installation.
The service life of the equipment is more than 25 years. No maintenance is required, except for periodic cleaning of the grease trap.
With properly selected performance, it is necessary to clean such fat traps no more than once every 3-6 months, and when using specialized biological products-no more than once a year.
Complete set of sewer grease separator
- Separation plates - 2
- Connection pipe (socket) - 2
- Sealed lid with an industrial seal (manufactured in the EU)
- Stiffeners - steel profile pipes along the perimeter
- Separation plates - 2
- Connection pipe (socket) - 2
- Sealed lid with an industrial seal (manufactured in the EU)
- Stiffeners - steel profile pipes along the perimeter
Additional equipment for grease traps for sewage:
- A level sensor for fat products with an alert unit
- Silt level sensor with notification unit
- Overflow sensor with notification unit
- K - transition cast iron-PVC (PP, PE)
The equipment is certified in accordance with the legislation of the Russian Federation.
The quality control system is certified according to GOST ISO 9001-2011
The warranty for the grease trap is 5 years.
Specification
Length, mm | 1720 |
Width, mm | 1120 |
Height, mm | 1000 |
Capacity, m3/h | 11 |
Peak discharge, L | 750 |
Volume, L | 1000 |
Diameter of the pipes | 110 / 160 |
Entrance height (centered) | 800 |
Exit height (centered) | 700 |
Non-standard design | Possible |
