UNI T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter
UNI-T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter
UNI-T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter
UNI-T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter
UNI-T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter
UNI-T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter
UNI-T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter

UNI T UT18C Voltage and Continuity Tester 0~690V AC/DC Voltage Tester LCD Display Auto Range IP65 Waterproof Meter

Share on (10000003058735):


Price:

Quantity:


Product Overview

Description



Product Description


UNI-T UT18C Voltage and Continuity Tester
UT18 series are designed for testing AC/DC voltage, 3-phase voltage, phase sequence, continuity, and more. This series is
categorized as CAT IV 600V and meets IP65 standard. These voltage testers are perfect tools for electricians to quickly measure voltage levels in all environments. This series should NOT be used with 110V electrical systems.

Applications:
It is suitable for non-contact surface temperature measurement.




Specification


Item Model
UT18C
Warranty
1 Year
Place of Origin
Philippines
Brand Name
UNI-T





Voltage (V)
12V
8V±1V
24V
18V±2V
50V
38V±4V
120V
94V±8V
230V
180V±14V
400V
325V±15V
690V
562V±24V

Phase rotation test
57Vac～400Vac (3 phase)
√
Frequency: 50Hz~400Hz
Single lead (L2)
voltage detection
Operating voltage: 100V~690V
√
Frequency: 50Hz~400Hz
Continuity test
Resistance: 0Ω~100kΩ (+50% accuracy)
√
Beeper and LED light indication
RCD test
Operating voltage: 230V (50Hz~400Hz)
√
Polarity detection
Positive & Negative
√
Self-inspection
All LED or LCD
√
No power test
Operating voltage: 100~690V
√
Features
Voltage indication
LED
Exceed voltage
Voltage range: 713V~788V
√
Auto standby
Standby current＜10μA
√
Slient mode
All range
√
Work light
√
Low battery indication
Around 2.5V
√
LCD display (voltage)
6V~690V
±(1.5%+5)
LCD display (Frequency)
40Hz~400Hz
±(3%+5)
IP65
√
General Characteristics
Power
1.5V battery (R03)×2
Display
UT18C: 31mm x 20mm; UT18D: 73.5mm x 35.5mm
Product color
Red and grey
Product net weight
280g
Product size (W x H x D)
272mm x 85mm x 31mm


Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

What's in the box:
1 x UT18C Voltage Tester; English manual
