Available options | Multiskan SkyHigh | Multiskan SkyHigh with Touch Screen | Multiskan SkyHigh with Touch Screen and µDrop Duo Plate | Multiskan SkyHigh with Touch Screen and Cuvette | Multiskan SkyHigh with Touch Screen, Cuvette, and µDrop Duo Plate |
SkanIt software | ✓ | ✓ | ✓ | ✓ | ✓ |
Touch screen* | ✓ | ✓ | ✓ | ✓ | |
Cuvette reading capability | ✓ | ✓ | |||
µDrop Duo Plate | ✓ | ✓ |
Technical specifications | Description | |
Wavelength selection | Monochromator | |
Light source | Xenon flash lamp | |
Wavelength range | 200–1,000 nm with 1 nm steps | |
Readout range | Up to 4 absorbance units | |
Bandwidth | <2.5 nm | |
Linearity at 450 nm* | 0–2.5 Abs, 2% | |
Accuracy at 450 nm* | 1.0% + 0.003 Abs (0–2.0 Abs), 2.0% (2.0–2.5 Abs) | |
Precision at 450 nm* | SD <0.003 Abs or CV <1.0% | |
Plates | 6- to 48-, 96-, and 6-384-well plates***, Thermo Scientific µDrop Plates | |
Cuvette | Dimensions (H x W x D): 40–58 x 12.5 x 12.5 mm | |
Beam center height: 8.5 mm | ||
Beam window: ≥2 mm | ||
Measurement speed | 6 sec with 96-well plate | |
(starting from A1 back to A1) | 10 sec with 384-well plate | |
Plate shaking | Linear | |
Spectral scanning speed | 10 sec from 200–1,000 nm with 1 nm steps | |
Incubation range | From ambient temperature +2C to 45˚C”. | |
General specifications | ||
User interfaces | Stand-alone use: 7 in. touchscreen display | |
PC control: Thermo Scientific SkanIt Software | ||
Connections | 1 USB B port for PC | |
1 Ethernet port | ||
3 USB A ports for devices (USB memory device and Wi-Fi dongle) | ||
Main input | 100–240 V (50/60 Hz) | |
Max power consumption | <110 W | |
Power save consumption** | 7 W | |
Dimensions (H x W x D) | 265 x 295 x 445 mm (10.4 x 11.6 x 17.5 in.) | |
Weight | True weight: 10.6 – 11.5 kg (23.4 – 25.3 lb), depending on the model | |
