Digital AC Voltmeter XL5135 XIELI brand LED Display

Product Overview

Description

Digital Voltmeter XL5135



SPECIFICATIONS:



LED color: Red /  Blue / Green

Reading: 3.5 digits

Operating temperature: 0 to 50centigrade

Storage Temperature: -10 to +80 centigrade

Humidity: 20—80%

Over Range Protection: 1 or -1 shown in the display

Weight: 50g

Sample Frequency: 400ms

Power supply: DC5V/12V,AC9V/AC220V.

Special power source As your request

Dimension:W79mm x H42.5mm x D25.5mm

W79mm x H42.5mm x D55.5mm

Aperture Size: W76mm x H39mm

Mounting Method: Snap-in



DC power measure AC voltage
Model	Range	Power supply	Resolution	Input Resistor	Accuracy	Max.input voltage
XL5135V-1 (DC/AC)	AC199.9mV	DC5V	0.1mV	10MΩ	±0.5%+3 digit	AC10V
XL5135V-2 (DC/AC)	AC1.999V	DC5V	1mV	1MΩ	±0.3%+3 digit	AC35V
XL5135V-3 (DC/AC)	AC19.99V	DC5V	10mV	10MΩ	±0.5%+3 digit	AC250V
XL5135V-4 (DC/AC)	AC199.9V	DC5V	100mV	10MΩ	±0.5%+3 digit	AC400V
XL5135V-5 (DC/AC)	AC300V	DC5V	1V	10MΩ	±1.0%+3 digit	AC500V







DC power measure DC voltage
Model	Range	Power supply	Resolution	Input Resistor	Accuracy	Max.input voltage
XL5135V-1 (DC/DC)	±199.9mV	DC5V	0.1mV	100MΩ	±0.3%+1 digit	±10V
XL5135V-2 (DC/DC)	±1.999V	DC5V	1mV	100MΩ	±0.3%+1 digit	±35V
XL5135V-3 (DC/DC)	±19.99V	DC5V	10mV	10MΩ	±0.3%+1 digit	±250V
XL5135V-4 (DC/DC)	±199.9V	DC5V	100mV	10MΩ	±0.3%+1 digit	±400V
XL5135V-5 (DC/DC)	±500V	DC5V	1V	10MΩ	±0.5%+1 digit	±700V









Some of famous manufacturer of welding machine use our product. For example, Panasonic, Jasic,Riland and so on.









FEATURES



-Power supply  DC5V/12V,  AC9V/220V



-Ultra-bright LED display



-15.00mm digit height



-Blue / Red / Green/Purple displays available



-Polarity: Automatic Sensing



-Automatic Calibration upon zero reading for 0V input



-Low cost



-High accuracy



-Can be re-calibrated by adjusting the calibration potentiometer



-Connection cable included



-Easy to install, snap-in/mount in panel



-Ideal for auto, boat, industrial, commercial & domestic uses



-Decimal Point position can be selected by user



 * Dark filter color piece



* Certification ISO9001 & CE



* Easy to read under the high light(sunshine)





* High quality components(LSI) and high stability



* 70-80% components from internaitonal well know manufacturers



* Easy to use high accuracy





We use high quality and reliable components. The chip from Siemens, Panasonic, Microchip and so on. Connection from phoenix, Thomson. Potentiometers from Bourns, Tocos and others.

We have high efficient testing equipment: FLUKE , KEITHLEY , HP, HIOKIand on. And YAMAHA of Production equipment. Our daily production capability is 3000-4000pcs.

In 2001, we have got ISO9001 Quality Management System Certification. We are an excellent member unit of Xi'an Metrological Measuring Institute. Our products have passed CE authentication. We can produce environmental products which meet RoHS standard. Our factory promises: reasonable prices, short production time and satisfactory after-sales service. We hope to cooperate

with more customers for mutual development and benefits. We welcome the buyers to contact us.
