60KV 1200A FR1001 High Low Voltage CT Clamp Wireless Current Meter

Share on:

Price:$247.00 - $302.00
Price in USD:Details


Product Overview


Product Name: 60KV 1200A FR1001 High Low Voltage CT Clamp Wireless Current Meter

         Function:  On-line measurement of high voltage current,

                              Transformer current measurement

                              High-voltage line current measurement

 Application: substations,power plants, industrial and mining enterprises and testing stations,electrical maintenance departments for current detection and field electricalwork, can be used to measure the current of a high voltage line with insulation sheath below 60kV or bare wire below 35 kV . When not using the insulation rod, it can also beused as a high-precision low-voltage clamp ammeter, leakage current meter, can accurately split out the current or leakage current of 0.1mA





Wireless receiver


Insulation rob

1SET(total 5m)

Instrument bag


Detector battery

DC6V 7# alkaline battery(1.5V AAA×4)

Receiver battery

DC7.5V 5# alkaline battery(1.5V AAA×5)

Manual, certificate


Technical Specification


0.0mA~1200A (50/60Hz  Auto)



Clamp Diameter




Sampling Speed

About 2 times/second

Wireless Distance



High-low voltage current measurement

Power Supply

Hosts :DC6V Alkaline Dry Battery (1.5V AAA X 4);

Receiver:DC7.5V Alkaline Dry Battery(1.5V LR6x5)

Test Method

Clamp CT,

Meter Dimension

Hosts :W/T/H: 87mm×37mmx262mm ;

Receiver :W/T/H :100mmx35mmx204mm

LCD Dimension

Receiver LCD display: 62mm×44mm

Total Weight

2.9Kg (including insulation rod and battery.)

Overflow Display

Exceed measurement range overflow function: “OL ” symbol display

Data Storage

200 Groups

Data Storage Full

the symbol “FULL” mark will flash to indicate the memory has been full.

Battery Voltage

Detector: when the battery voltage is below 5.2V, the symbol of low power will show to remind to replace battery. Receiver: when the battery voltage is below 5.2V, the symbol of low power will show

Insulated Rod

5 section insulated rod(total 5m)

Insulation Intension

AC 60KV/rms

Circuit Test

Insulation sheath wire test below 60kV line voltage, bare wire test under 35kV (with insulation rod operation)

Work Temperature


Storage Temperature



0~3175%, 31~40℃≤50%

Suitable for Safety Regulations

EC1010-1, I1010-2-032, Pollution Level 2, CATⅢ(600V) IEC61326 (EMC Standard)
