swing barrier gate turnstile 24v 8A servo drive with RS232 RS485 CAN turnstile servo drive
- Category: Motor Driver >>>
- Supplier: Shenzhen Jiayu Mechatronic Co. Ltd.
Share on (11000000699271):
Product Overview
Description
Product Description
Features
Suitable for DC servo motor, support incremental encoder feedback with HALL.
Integration of industry-leading channel movement control logic,real time detection of the status of the movement, meet the requirements of safe passage.
For use scenarios such as violent brake breaking, internal design has a special circuit to ensure the stability of the driver and power supply.
Support RS232, RS485 and CAN, provide Modbus communication protocol, suitable for third party controller.
Equipped with digital/LCD display keyboard debug tools.
Specification
item | value |
Warranty | 3months-1year |
Place of Origin | China |
Brand Name | jiayu |
Model Number | EPS2408-AD-R-N-T |
input voltage | 24v |
Rated/Peak Current | 8A/24A |
Feedback | Incremental Encoder with HALL |
Communication | RS232/RS485/CAN |
DigitalI/O | 4 IN 3 OUT, Optocouplers Isolation |
special interface | 1 output for clutch brake |
Hardware Protection | Low voltage Over voltage Over current Over heating |
Working Temperature | -10℃~55℃ |
Packing & Delivery
standard package
Company Profile
Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.
The company's technology stems from mature domestic and foreign technology transfer and independent research and development. The products are localized and the core technology is independently controllable.
The company introduced advanced control technology and manufacturing technology from Germany and Switzerland, and has an experienced R&D and manufacturing team. In the application field of security gate control gate equipment, it has realized infrared and light curtains. The industry's logic and control technology for the gate movement module, the self-developed and manufactured electronic control module for pedestrian passage gates and vehicle barrier gates have covered customers in various industries such as high-speed rail stations, subway stations, airports, ports, highways, etc. group.
Since its establishment, our company has won the recognition and support of our customers by virtue of "excellent quality, honest service". Now the factory covers an area of more than 2,000 square meters and has passed the ISO9001:2015 quality management system certification. In the channel gate equipment industry, tens of thousands of electronic control products developed and manufactured by Jiayu Mechatronic Co., Ltd. have been shipped on supporting customers' complete equipment, which are spread all over the country, as well as overseas regions such as Europe, Middle East, and Southeast Asia. The field has contributed a lot.
In the future, the company will focus more on the improvement of product performance and quality, and continue to build the top brand of electronic control of channel gates.
The company's technology stems from mature domestic and foreign technology transfer and independent research and development. The products are localized and the core technology is independently controllable.
The company introduced advanced control technology and manufacturing technology from Germany and Switzerland, and has an experienced R&D and manufacturing team. In the application field of security gate control gate equipment, it has realized infrared and light curtains. The industry's logic and control technology for the gate movement module, the self-developed and manufactured electronic control module for pedestrian passage gates and vehicle barrier gates have covered customers in various industries such as high-speed rail stations, subway stations, airports, ports, highways, etc. group.
Since its establishment, our company has won the recognition and support of our customers by virtue of "excellent quality, honest service". Now the factory covers an area of more than 2,000 square meters and has passed the ISO9001:2015 quality management system certification. In the channel gate equipment industry, tens of thousands of electronic control products developed and manufactured by Jiayu Mechatronic Co., Ltd. have been shipped on supporting customers' complete equipment, which are spread all over the country, as well as overseas regions such as Europe, Middle East, and Southeast Asia. The field has contributed a lot.
In the future, the company will focus more on the improvement of product performance and quality, and continue to build the top brand of electronic control of channel gates.
