Испытательная камера для внешнего короткого замыкания батареи, испытательная машина для безопасности аккумулятора, испытательная машина для внешнего короткого замыкания аккумулятора
- Category: Battery Testers >>>
- Supplier: Dongguan Lizjin Electronic Technology Co. Ltd.
Share on (11000003873191):
Product Overview
Description
Product Description
Product Application
This temperature controlled external short circuit test system integrated a variety of battery short circuit test standard requirement and design. This testing system which is able to simulate the actual testing and performs cell voltage measurement with various environmental conditions applied such as temperature&humidity and crushing pressure. The system is designed based on IEC 62133-2012 8.3.9 testing standards which helps ensure the battery safety and reliability.
Specification
Model | LZJ-DC-963 |
Working Voltage | AC 220V/380V 50/60 Hz |
Power | 2000W |
Maximum short circuit current | 2000A, can be customized |
Max. battery voltage | 100V |
Max. impact Voltage | AC 1KV/1.2 - 50 us 1min |
DC Response time | < 5 micron seconds |
Short circuit resistance | ≤5mΩ |
Movement time | Pull in time/release time ≤30ms |
Performance characteristic | Cold pull in voltage ≤66%Us Cold state release voltage ≤30 Us, ≥5%Us |
Temperature Range | RT+10~200°C |
Temperature control precision | 0.1℃ |
Temperature uniformity | ±1℃ |
Test box size | 400*450*400mm, can be customized |
Service life | > 300K times of use |
Work environment | Temperature -40℃~100℃, humidity 10%~90% no condensation |
Applicable standards | UL2054; IEC62133;UN38.3;QC/T744-2006 |
Detailed Images
Packaging & Shipping
Company Information
Our products
Our Services
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
Pre-sales service
*24-hour Online contact
*Choose the right model of the equipment according to customer's request
Middle service
*Give the best offer
*Support customization
* Do customer's request
*Choose payment term you convenient.
*Promptly production and delivery inform you in time.
*Can provide invoice value as you like to decrease your tax
After sale service
*1 year warranty service and all life maintenance
*Provide Free information (1. Product Instruction 2. Product
operation instruction/video 3. Experiment Test)
*Remote control technical consult
*Free installation DVD
*Maintenance plan
Certifications
FAQ
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),we have our own factory.
Q:Do you accept customization service?
A:Yes, we can not only offer standard machines, but also customized machines according to your request. We will design until you are satisfied.
Q:What is your product warranty ?
A:1Year warranty, but lifetime for services.
Q How about the products quality?
A: Our products apply to ISO, ASTM, GB, etc.
