SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes
SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes
SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes
SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes
SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes
SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes
SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes

SS310 DO214AC Schottky Diodes Rectifier 40 45 50 MIL SMD Diode 100V 3A Surface Mount SS24 SS26 SS110 SS210 Diodes

Share on (11000004853957):


Price:

Quantity:


Product Overview

Description



Product Description


Product Name
SS310 SMD surface mount rectifier diode
Material
silicon , epoxy
packaging type
SMA
chip size
40 mil; 45 mil; 50 mil
Feature
maximum peak reverse voltage：100V
maximum average rectified current:3A
maximum forward peak surge current:100A
maximum reverse current:0.5mA
maximum forward voltage:0.85V

packing
3KPCS/ROLL; 10KPCS/ROLL










Packing&Shipping


experienced packing & shipping

1: if you have shipping forwarder in China, we can ship the goods to your shipping forwarder.

2: if you don't have shipping forwarder in China, we can ship by express, by air , by sea.

3: accept drop shipping.

4: all the goods will be packed by ourselves delicately in our factory , we will protect the goods pretty well.

5: we cooperate with some shipping companies who are very reliable and offer best service for us, most importantly , competitive shipping freight .
