Buy cheap sales Hydraulic Excavator Mini Excavators 0.8 ton Mini Excavators with EPA CE
- Category: >>>
- Supplier: AUER TRADE GmbH
Share on (11000008431005):
Product Overview
Description
Buy cheap sales Hydraulic Excavator Mini Excavators 0.8 ton Mini Excavators with EPA CE
Mini excavator has a multi-purpose machine, small radius of gyration, adjustable dozer blade, easy to disassemble simple shed, 360 degree rotation, small size, light weight, good transportation, low fuel consumption, high efficiency, stable performance, safe and reliable, operation Flexible and convenient, and a wide range of adaptability.
Mini Excavators Small Crawler Digger 800kg specification
| Model | NT08 | |
| Bucket capacity : | 0.02 | |
| Standard bucket width(mm) : | 320 | |
| Total weight(Kg) : | 800 | |
| Machine size (transportation) | Length(mm) : | 2480 |
| High(mm) : | 1150 | |
| Width(mm) : | 722 | |
| Minimum ground clearance (mm) : | 85 | |
| Motor | KOOP 192F or changchai engine | |
| Power(KW/rpm) : | 8.6 | |
| Digging performance | Maximum digging height(mm) : | 2400 |
| Maximum unloading height(mm) : | 1650 | |
| Maximum digging depth(mm) : | 1220 | |
| Maximum vertical digging depth(mm) : | 2460 | |
| Maximum digging radius(mm) : | 2450 | |
| Large arm deviation (left/right)(mm) : | 70/50 | |
| Front minimum radius of gyration(mm) : | 1120 | |
| Rear minimum radius of gyration(mm) : | 400 | |
| Bucket digging force(KN) : | 7.5 | |
| Stick digging force(KN) : | 8.3 | |
| Crawler | Crawler type : | Rubber crawler |
| Crawler width(mm) : | 150 | |
| Crawler length(mm) : | 1140 | |
| Walking part | Track center distance(mm) : | 572 |
| Wheel spacing(mm) : | 420 | |
| Travel speed (S/H)(Km/h) : | 2 | |
| Gradeability(°) : | 30 | |
| Rotary height(rpm) : | 12 | |
| Bulldozer | Width(mm) : | 722 |
| High(mm) : | 180 | |
| Lifting distance (up/down)(mm) : | 125 | |
| Hydraulic pump type : | Gear pump | |
| Rotary motor : | Eaton, United States | |
| Travel motor : | Eaton, United States | |
| Fuel tank capacity(L) : | 10 | |
| Hydraulic tank capacity(L) : | 16 | |
