industrial dry grain vacuum feeder low noise plastic Jewelry Conveyor plastic particles auto loader Suction machine in Thailand
- Category: Plastic Raw Material Machinery >>>
- Supplier: Chaozhou Longhe Plastic Machinery Co. Ltd. Guangzhou Branch
Share on (1209986924):
Product Overview
Description
Application and praperties:
1,Application to conveying nonstick powder and granules mixture,including resin powder,bakelite powder and paints;
2,Eliminating dust flying during the transfer,realizing dust-free operation in workshop;
3,High-pressure air injection to shatter dust instantly,ensuring smooth powder suction;
4,Stainless steel hopper ensuring no material pollution,easy to clean;
5,Microcomputer touch-type control,easy and simple to operate.
Technical parameters:
Model | AS-300G | AS-400G | AS-800G | AS-800G2 | AS-900G | ||
Motor power(w) | Type | Carbon Brush Type | Induction Type | Induction Type | Induction Type | Induction Type | |
Specification | 950 | 750 | 750 | 1100 | 3000 | ||
Voltage Specification | 1Φ,220v,50HZ | 3Φ,380v,50HZ | 3Φ,380v,50HZ | 3Φ,380v,50HZ | 3Φ,380v,50HZ | ||
Material Feeding Capacity(kg/h) | 300 | 400 | 400 | 550 | 600 | ||
Suction Lift(M) | 4 | 4 | 4 | 4 | 4 | ||
Static Air Pressure(MAX) | 1500mm/HZO | 1800mm/HZO | 1800mm/HZO | 1800mm/HZO | 3000mm/HZO | ||
Storage Tank Capacity(L) | 6 | 10 | 7.5 | 7.5 | 10 | ||
Internal Diameter of Conveying Pipe(mm) | Φ38 | Φ38 | Φ38 | Φ38 | Φ38 | ||
Overall Diamension(mm) | Hopper | / | / | 460x380x550 | 460x380x550 | 460x380x700 | |
Main Unit | 400x360x600 | 400x300x500 | 400x300x440 | 400x300x440 | 500x400x600 | ||
Weight(kg) | 11 | 28 | 55 | 65 | 85 | ||
