Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine
Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine
Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine
Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine
Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine
Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine
Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine

Zhongji Continuous PU Sandwich Panel Machine | polyurea sandwich panel machine

Share on (1387799069):


Price:$400,000.00

Quantity:


Product Overview

Description























ITEMS
TYPE/UNIT
SP-PU-C
Color Steel Sandwich Panel Specifications
mm
Width: 700 ~ 1000
Thickness: 30 ~ 150
Production Line Speed
m/min
3~8
The Maximum Temperature of The Hot Air Circulation
°C
70
Total Power
kw
300
Line Dimensions (L × W × H)
mm
 86000×7000×3800
The Total Installed Power Capacity
kw
207
Stove Power
kcal
200,000
Double Belt Iaminated Conveyor Length
m
24



Main Features:

1. Panel from the continuous sandwich panel production line is a composite structure consisting of two external facings and an insulating core. The core can be flexible with Polyurethane, Mineral Wool, Glass Wool, PIR, Phenolic or EPS. Various profiles are available according to customer's requirement with pre-painted steel sheets, PVC sheets, Aluminum paper or other similar supports.

2. The continuous sandwich panel production line has a large scale production capacity. It allows a uniform distribution of the reactive mixture, a homogeneous density, suitable physical and mechanical characteristics.

3. Roof panels, wall panels and door panels are mainly made of metal section support and polyurethane insulating mass.

4. The capacity of the continuous line is 3-7m/min, length of the production line is 100m, the size of the final panel is 3-18m long, 900-1200mm wide, 20-150mm thick, the valid length of double belt conveyor is 24m, the total power is 300kw.
