ZX 320 PS offset printer

Product Overview

Description

ZX-320 PS offset printer



usage:





1,zx-320 machine adopts exact servo  control system which can ensure the stablilization when the printing material in the printing process.The operation of this machine is fast,convenient and aimple.

2,printing unit:adopting high quality and heavy offset printing unit,assembled with 19 pieces of ink rollers, 4pcs of form rollers and 4 pieces of water rollers ,has nice ink woring system to avoid streak trouble and ghost image efficiently, largely increase the printing quality .The definition and precision made would never be reached by flexo press.

3,shaftless transmission system:every printing unit transmitted by an independent servo motor,15sets of sevo motors in total for whole in total for whole machine to ensure the exact color registering precision during high speed operation.

4,Positioning system:The only work is to input the printing length on the main control panel, every unit will be motioned to the right position automatically.Largely saves time and materials when adjust the color register.

5,Color registering system:the vertical and horizontal motions of every printing unit are all controlled by independent motor. By video still system, the machine can regulate vertical &horizontal registering without stopping ,it improves the printing quality and increases the producing capacity.

6.Super large printing area300x350,the maximun printing lenght could be reached at350mm,and the running maximumspeed is 63m/min, by high precision photocells, the machine ensures  multi-register print on both side, make the possibility of label pattern variety.

7,Every printing unit equips with cluth device to be stopped  independently by lifting away when needed.This system extends the machine using life.

8,Multi options:flexo UV varnishing unit and rotary die-cutting unit can be option for this machine.Only one big magnetic die-cutting cylinder used in this machine,largely saves the tooling cost.Different die-cutting job can be achieved only by changing the flexible die.

9,Touch LCD screen, faster CPU, 12inch operating display,independent touch screen in each printing unit, powerful human -computer dialogu system,multi-guide inspecting display interface ,instant alarm signal, makes operation much easier and more efficient.

10,PS plate intermittent printing adopted, hits the high-leverl demand whatever high, mid or low capacity printing task,and it is an ideal choice for print firms to produce the high-grade adhesive labels.









Model	320
Printing speed	50-180T/min
Printing color	2-6colors
Max printing length	350mm
Max web width	320mm
Max printing width	300mm
Max unwinding diameter	600mm
Max rewinding diameter	600mm
Power supply	3phase 380v
Total power	33.6kw(without UV power)
Main machine size	8850mmX1600mmX1850mm(LxWxH)
Main machine weight	about9.5t





Remark: If you have interest,please feel free to contact us,we will provide you details.thanks.





label offset printing machine
1. high accuracy and top level quality
2. automatic , easy operation
3. efficient production
