1.The conventional fire alarm control system control panel general description:
-- The AW-CFP2166 is atranditional type of fire alarm control paneldesigned based on EN54 part 2&4 standard.
--It is steady and widely used to work with other brands fire alarm detectors/sensors like manual call point/break glass, smoke detector, heat detector, combined smoke and heat detector, strobe with sounder, flash light, fire bell, etc.
-- It is modularized design, the panel can extend from 1 zone to 32 zones easily.
2.Details of the conventional fire alarm control system control panel :
1) The outlook of the conventional fire alarm control panel:
2).The characteristics of the conventional fire alarm control system control panels:
Model
AW-CFP2166 , 1 to 32 zones
Design principle
The series conventional fire alarm panel is designed based on EN54 part 2&4 standard.
control mode
2 level control mode by a lock
power supply output
27VDC
signal output
Has FIRE PROTECTION, FIRE ROUTING and FAULT signal output; the output can be configured to dry relay type or wet sources type.
sounders output
Has 2 channel general sounders output.
Special function
Each zone has 1 circuit detectors input .
Each zone can be disable by a button.
It has RESET button to reset the panel.
It has SILENCE button to stop BUZZER and SOUNDERS.
It has EVACUATE button to start a manual fire alarm immediately.
It has TEST button to test all LEDs orderly.
It has battery low protection function, when battery voltage lower than 21VDC, battery will be cut off automatically until the mains power is on.
It has an optional GSM module for fire alarm by SMS .
factories, hospitals, restaurants, hotels, schools, business buildings, government buildings,etc.
Advantage
Efficient feedback, steady and easy to work with other brands fire products,Humanization setting, Economic, User friendly,etc.
3. Main technical parameters of AW-CFP2166 conventional fire alarm control panel:
ITEM
1 Zone panel
2 Zone panel
4-8 Zone panel
4-32 Zonepanel
Model No.
AW-CFP2166-01
AW-CFP2166-02
AW-CFP2166-04-16
AW-CFP2166-04-32
Power specification
Mains supply voltage
110VAC or 240VAC
Internal power supply
27.2VDC
Total output current limited
500mA @ 240VAC
500mA @ 240VAC
3A @ 240VAC
3A @ 240VAC
Main supply monitor for fault
Yes
Battery protection for low voltage
Yes
Batteries (default configuration)
12V2AH*2
Detector circuit specification
Number of circuit
1
2
4-16
4-32
Maximum number of smoke/heat detectors per zone
20 (based on a total detector current of 2mA, each detector consuming 100μA).Note: if End of Line Monitor Unit is fitted, for correct operation maxmum voltage drop must not exceed 12 volts.
Ø Delivery Time: 3 - 5 days after payment received
Ø Shipping: delivery by air, ship or DHL, FEDX etc. Express for your order
