Economic hydraulic agricultural trailer tipping trailer trailer sale

Different Sizes For Fully Welded Hydraulic Tipper Trailer

SIZE

MODEL NO

OVERALL SIZE

DECK SIZE

SPRING

WHEEL

SURFACE TREATMENT

ATM

8x6Ft

SWT-HTT86

4150x2330x800mm

2440x1830mm

7leafs

7.50R16LT

Hot Dipped Gal

3500KG

9x6Ft

SWT-HTT96

4450x2330x800mm

2745x1830mm

7leafs

7.50R16LT

Hot Dipped Gal

3500KG

10x6Ft

SWT-HYT106

4760x2330x800mm

3050x1830mm

7leafs

7.50R16LT

Hot Dipped Gal

3500KG

Description For 9x6 Fully Welded Hydraulic Tipper Trailer

Drawbar

100x50mm RHS. 1600mm long with 2x10mm safety chain

Lower Chassis

100X50mm RHS (Not angle)

Upper Chassis

100X50mm RHS (Not angle)

Floor & Side Panels

2.5mm Checker plate, fully welded to upper chassis (Not cheap Ribbed zinc plate)

Mudguard

2.5mm Checker plate

Axle

63mm Solid Round Axles, 12" Electric Brakes on 4 Wheels

Spring

7leafs rocker roller suspension (not 5leafs or 6leafs cheap and light spring)

Wheel

16inch wheel with white paint rim

Jockey wheel

10inch top wind heavy duty jockey wheel. (E-mark & DOT)

Coupler

50mm AU standard coupling, 1 7/8 NZ standard coupling, EU standard coupling

Lights

LED Lights with 7pin plug and 7 core wiring. E-mark and DOT certificated

Toolbox

2.5mm check plate Toolbox for Battery and Motor

Tipper Sys.

5 stage ram

45 degree box tipping

3500KGS tipping capacity

Motor

12V, 15L, oil tank

Surface Treatment

Hot dipped galvanized
