Product Overview

Description





Product Description


DMD is made of Dacron fabric on both sides and polyester film as middle layer , with 3 layers lamination , it has very good high voltage protection and mechanical strength ,widely used for all kinds of motors.




Specification


Name：
DMD B
Thickness and Tolerance:
0.15mm +/-0.02 , 0.18mm +/-0.02
0.20mm +/-0.02 , 0.25mm +/-0.02
0.30mm +/-0.03 , 0.35mm +/-0.02
0.40mm +/-0.03 , 0.45mm +/-0.03
Standard width:
1000mm +/-10
 Package:
50 kgs +/-5 per roll
 Breakdown voltage:
0.15mm ------6kv , 0.18mm---7kv
0.20mm ------8kv , 0.25mm----10kv
0.30mm-------11kv , 0.35mm-----13kv
0.40mm-------16kv , 0.45mm-----19kv
Thermal Class:
B (130 degree)
 Standard:
IEC60626-3-500


Name：
DMD F
Thickness and Tolerance:
0.15mm +/-0.02 , 0.18mm +/-0.02
0.20mm +/-0.02 , 0.25mm +/-0.02
0.30mm +/-0.03 , 0.35mm +/-0.02
0.40mm +/-0.03 , 0.45mm +/-0.03
Standard width:
1000mm +/-10
 Package:
50 kgs +/-5 per roll
 Breakdown voltage:
0.15mm ------6kv , 0.18mm---7kv
0.20mm ------8kv , 0.25mm----10kv
0.30mm-------11kv , 0.35mm-----13kv
0.40mm-------16kv , 0.45mm-----19kv
Thermal Class:
BF(155 degree)
 Standard:
IEC60626-3-500


Why Choose Us


Advantages:
The thermal class covers: B, F, H, N,and C , the enterprise is managed strictly according to ISO9001 system (Registered No.: E03817Q01957R2M), and passed UL approval ( File No. : E345432) ,all products comply with IEC standard and ROHS as well as REACH test.
Applicable Industries:
Our products are widely used for wind power ,thermal power generation , civil aviation,railway , military project ,motor and transformer Etc.




Packing & Delivery


Packing：Carton packaging, large size is pallet packaging
Delivery：Shipping, Shanghai special line





Company Profile


Yancheng Advanced Insulation Co.,Ltd is an esteemed insulation material manufacturer with brand ADAS registered , which mainly produce fiberglass insulation sleeving (yearly production 200 million meters), flexible lamination (3500 tons/year) , woven tape ( yearly production 50 million meters) .






Factory workshop




Certifications




FAQ


Q1:What is the payment term?
A:T/T or L/C.

Q2:What is the shipping port?
A:Shanghai Port.

Q3:What is the delivery time?
A: 25 working days

Q4:What is the quality level of your product?
A:International Standard.

Q5. Are you factory or a trading company ?
A: Factory

Q6: when did you found ?
A:  In July 2007

Q7: How many employee in your company ?
A: 110
Any question，please let us know and contact us！
