Shengrun skeletal trailer can be configured for specific container combinations, minimizing the unladen weight. Can be configured individually for: 20h, 30', 40', 45', 2x20' or any combination of all of these containers.
FEATURES AND BENEFIT SUMMARY
Galvanised pull out coupling assembly – coupling assembly for use when carrying 13.6m or 45’ containers for ease of attaching Susies
Galvanised pull out crash bar assembly – for use when carrying 45′ or 13.6m containers
Air operated locking pins – parking brake won’t release until pins are in operating position
Patented 14 lock design – allows transportation of all container configurations and sizes
Revolutionary pin and roller design– both can be changed easily without having to split the complete trailer apart
Stainless steel wear pads – minimise wear to the chassis and alleviates rusting.
Dimension
12400*2500*1550mm
Container Locks
4 to 12 Euro Standard Container Locks
Tare Weight
Approx. 6.2 T
Axles
BPW, FUWA or Certificated Chinese Axles
Loading Capacity
30-45 T
Suspension
Air, Mechanical or Bogie Suspension, Front Axle Lifting for air suspension
Main beam
Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm; Material is Q345B steel
Brakes
Wabco ABS and EBS brake system
Parking leg and King pin
JOST or China brand parking leg and king pin
Side beam
16mm channel steel (Material is Q235B steel)
Rims
Steel or Aluminum Rims / 9.00*22.5/8.00-20/8.5-20
Bottom Platform
3mm checquered steel plate
Tires
12 R 22,5 13 R 22,5 12 R 24
Packaging & Shipping
We will arrange the most cost-effective transportation mode according to the quantity of products. All trailers and trucks will be polished with wax before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
Packaging Types:
Bulk Way | Container Way
Advantages
Company Information
Shandong Shengrun Automobile Co., Ltd. is a full-size Modified Truck enterprise which integrates the design of product, scientific research developing, production and sale together, possessing subsidiary companies of automobile production, automobile trade and automobile fittings production, etc. Our leading products include "Shengrun" brand semi-trailers, tipper, fuel tanker, particle material tanker, bulk cement tanker, concrete mixer truck, wrecker trucks, LNG, CNG, and other special vehicles
Certifications
Trade Shows
FAQ
Q1. Are you a factory or trading company: We are a factory specialized in manufacturing kinds of semi trailers. You are very welcome to visit our facilities and production line at any time. Q2. Could you accept special design and specification? Sure of course. our professional engineers and our well-trained staff will produce according to customer special requirements. Such as: special Size, special structure, or OEM, etc. Q3. Do you have stock? Yes we have a few stock in our warehouse for your urgent order. Q4. Do you have overseas aftersales service? Normally twelve months warranty to main beam of the vehicle. As to the quality problem, buyer should provide pictures of the bad assembly, after confirmed by our technician; we provide new part for the buyer.
OEM Service
If you ...
1. Are looking for OEM/ODM manufacturers in this industry.
2. Need someone that can produce what you want and have a custom design printed to your specification.
