HM 6561 portable hardness tester Leeb hardness tester

Product Overview

Description



HM-6561 Leeb Hardness Tester

Application

Measure the hardness of metal workpiece. Applicable to Die cavity of molds, Inspection of bearing and other mass produced parts on a production line.



Features

* Palm size for narrow space.

* Test at any angle, even upside down.

* Direct display of hardness scales HRB, HRC, HV, HB, HS,HL.

* Large memory could store 50 groups including single measured value, impact direction, material and hardness scale etc.

* User recalibration function allowed.

* Manual or automatic shut down.

* Low battery indication.

* Use USB/RS-232 data output to connect with PC.

* Provide Bluetooth data output choice.

Material Selection

Material	Converting Ranges
	HL	HRC	HRB	HB		HS	HV
				30D²	100D²
Steel & Cast St.	300~900	20.0~68.0	38.4~99.5	80~647		32.5~99.5	80~940
C.W.Tool Steel	300~840	20.4~67.1					80~898
ST.Steel	300~800	19.6~62.4	46.5~101.7	85~655			80~802
Gray Cast Iron	360~650			93~334
Nodular Cast Iron	400~660			131~387
Cast Aluminum	174~560				20~159
Brass	200~550		13.5~95.3		40~173
Bronze	300~700				60~290
Copper	200~690				45~315

Specifications

Display	LCD
Materials	9 different common materials(Steel&Cast Steel,C.W.Tool Steel,Stainless Steel,Gray Cast Iron,Nodular Cast Iron,Cast Aluminum,Brass,Bronze,Copper)
Measuring Range	200~900(HLD)
Accuracy	Display Error±0.8%
Repeatability	±0.8%
Conversion	HL-HRC-HRB-HB-HV-HSD
Memory	50Data Can Be Stored And Re-readable
Impact device	Probe D,Weight:75g
Storage Temperature	-30~60ºC
Operating Conditions	Temperature	-10~50ºC
	Humidity	<90%RH
Power Supply	2X1.5V AAA(UM-4)Battery
Dimensions	146x65x36mm
Weight	130g(Not Including Batteries)
