Spherical Roller Bearing NSK 21318 bearing 21318K 21318CC/W33 21318 E/C3
- Category: >>>
- Supplier: Jinan Kelunte Bearing Co. Ltd
Share on (1600201782965):
Product Overview
Description
Spherical Roller Bearing NSK 21318 bearing 21318K 21318CC/W33 21318 E/C3
Product Description
| Bore Diameter | 90 mm |
|---|---|
| Outside Diameter | 190 mm |
| Overall Width | 43 mm |
| Bore Type | Straight |
| Outer Ring Type | Not Split |
| Internal Clearance | C3 |
| Closure Type | Open |
| Lubrication Hole Type | Lubrication Groove & Hole |
| Dynamic Load Capacity | 380 kN |
| Static Load Capacity | 450 kN |
| Maximum RPM | 4800 RPM |
| Operating Temperature Range | Maximum of +390 °F |
| Model | Boundary Dimensions (mm) | Basic Load Rating (KN) | Mass | |||||
| D | D | B | C | Co | Kg | |||
| 21307 | 21307K | 21307W33 | 35 | 80 | 21 | 70.70 | 73.30 | 0.547 |
| 21308 | 21308K | 21308W33 | 40 | 90 | 23 | 87.60 | 92.00 | 0.751 |
| 21309 | 21309K | 21309W33 | 45 | 100 | 25 | 105.00 | 112.00 | 1.010 |
| 21310 | 21310K | 21310W33 | 50 | 110 | 27 | 121.00 | 129.00 | 1.300 |
| 21311 | 21311K | 21311W33 | 55 | 120 | 29 | 141.00 | 152.00 | 1.660 |
| 21312 | 21312K | 21312W33 | 60 | 130 | 31 | 165.00 | 175.00 | 1.990 |
| 21313 | 21313K | 21313W33 | 65 | 140 | 33 | 186.00 | 197.00 | 2.450 |
| 21314 | 21314K | 21314W33 | 70 | 150 | 35 | 206.00 | 223.00 | 2.980 |
| 21315 | 21315K | 21315W33 | 75 | 160 | 37 | 249.00 | 270.00 | 3.630 |
| 21316 | 21316K | 21316W33 | 80 | 170 | 39 | 272.00 | 306.00 | 4.290 |
| 21317 | 21317K | 21317W33 | 85 | 180 | 41 | 297.00 | 351.00 | 5.190 |
| 21318 | 21318K | 21318W33 | 90 | 190 | 43 | 320.00 | 387.00 | 6.090 |
| 21319 | 21319K | 21319W33 | 95 | 200 | 45 | 366.00 | 500.00 | 7.150 |
| 21320 | 21320K | 21320W33 | 100 | 215 | 47 | 397.00 | 546.00 | 8.810 |
| 21322 | 21322K | 21322W33 | 110 | 240 | 50 | 460.00 | 634.00 | 9.460 |
more product
Packaging & Shipping
Packing &Delivery
Our Services
Company Information
Jinan Kelunte Bearing Co., Ltd. is a professional deep groove ball bearing manufacturer and is engaged in the imported bearings.Our company is engaged in the imported bearings,company's main imported Roller Bearing,Ball Bearing,deep groove ball bearings,taper roller bearings,angular contact ball bearings,Pillow Block Bearing etc.
