Dersion Cargo Air Shower PVC Rolling Door Manufacturer Cargo Air Shower

Specification

W*D*H

2500*2266*2200

2500*2766*2200

3000*2766*2200

3000*3266*2200

The main material

Cold rolled steel sheet electrostatic spraying or stainless steel

5mm double-layer tempered glass with automatic door closer

Filtering system

2pcs

4pcs

4pcs

4pcs

Primary filter：G4               specification：595*295*25mm

HEPA：99.99%（0.3um） specification：610*610*70mm

Fan/speed

2pcs

4pcs

4pcs

4pcs

Speed 25～30m/s

Nozzle

18pcs

32pcs

32pcs

36pcs

Stainless steel embedded type or 360 degree rotating type

Control system

Der-1series intelligent control system
10-inch touch LCD screen, ARM main control, multi-core CPU, high-speed main frequency;
Voice prompt, adjustable blowing time 0-99S, double door electronic interlock, PDF/JPG picture, video and multiple file play function;
A variety of scene function programs, you can choose according to your needs, and with password permission settings;
Intelligently judge the connection status, running status and fault self-check function of each component, and can be connected to the central plant monitoring system;
Various sensors such as wind speed, pressure difference and falling dust are optional, and each module interface is reserved.

Illumination

LED recessed lighting

Power

3.1KW

4.6KW

4.6KW

4.6KW
