Product Description 1.Faster acquisition technology, achieve the high-speed scanning by the RF / gradient dephasing and other high¬speed scanning technologies, reduce the production of respiratory motion artifacts at most.
2.Humanized software interface, fast and intelligent scanning for localization images, help users to master the scanning skills for all parts of the body in shortest time.
3.High openness magnet, good for MRI interventional operation.
4.Available for real time display and analysis, imaging browsing and management with simple operation interface and powerful software. It meets the requirements of fast diagnosis by visual user interaction and 3D position technology, powerful positioning processing capacity, new version with optimized scanning process.
5.High efficiency full digital RF Amplifier system, modular design full digital spectrometer system, perfectly realize various imaging technologies, greatly enlarge the sequences' application range.
6.High performance magnet materials promise the stability of the magnet. Advanced magnet eddy current free technology ensures the imaging quality. Based on different sequences and scanning environment, dynamically adjust the magnetic field, 4D active shimming technology guarantees the high uniformity of magnetic field.
7.High precision temperature control system of magnet, guarantee the stability of magnetic field strength, ensure the stability of imaging quality in long term, save the cost for users.
8.High precision temperature control system of magnet, guarantee the stability of magnetic field strength, ensure the stability of imaging quality in long term, save the cost for users.
No.
Item
Specification
1
Magnet System
1.1
Magnet Type
Permanent magnet with automatic constant temperature system
1.2
Field strength
0.42T
1.3
Magnet shape
C-shape
1.4
Homogeneity (40cm, DSV, VRMS)
2ppm
1.5
Shim method
Active/Passive/Dynamic
1.6
Magnet vertical gap
40cm
1.7
Accessibility (Horizontal opening angle)
250°
1.8
5 Gauss fringe field
2.5m*2.5m*2.5m
2
Gradient System
2.1
Gradient field strength (Single Axis)
31mT/m
2.2
Gradient slew rate (Single Axis)
107mT/m/ms
2.3
Rise time
0.29ms
2.4
Gradient cooling system(Gradient coils and power electronics)
Air
3
RF System
3.1
Spectrometer
Fully digital
3.2
RF system type
Digital Transmit and Receive
3.3
Number of RF channel
4
3.4
Transmitter amplifier peak power
6kW
3.5
RF bandwidth of receiver
Each 400KHz
3.6
Dynamic range
80dB
3.7
Noise factor
0.3dB
3.8
Coil type
phase array
3.9
Head coil
Yes
3.10
Neck coil
Yes
3.11
Body coil (small)
Yes
3.12
Body coil (large)
Yes
3.13
Knee coil
Yes
3.14
Ankle coil
Yes
3.15
Shoulder coil
Optional
3.16
Soft coil
Optional
