Model | Lifting Capacity (Ton) | Chain (mm) | Lifting Height (M) | Running Speed (M/Min) |
|
HHBB0.5-01 | 0.5 | φ6.3*1 | 7.2/2.4 | 11/21 | |
HHBB01-01 | 1 | φ7.1*1 | 6.9/2.3 | 11/21 | |
HHBB01-02 | 1 | φ6.3*2 | 3.6/1.2 | 11/21 | |
HHBB1.5-01 | 1.5 | φ10.0*1 | 8.8/2.9 | 11/21 | |
HHBB02-01 | 2 | φ10.0*1 | 6.6/2.2 | 11/21 | |
HHBB02-02 | 2 | φ7.1*2 | 3.3/1.1 | 11/21 | |
HHBB2.5-01 | 2.5 | φ11.2*2 | 5.6/1.8 | 11/21 | |
HHBB03-01 | 3 | φ11.2*2 | 5.6/1.8 | 11/21 | |
HHBB03-02 | 3 | φ10.0*2 | 3.3/1.1 | 11/21 | |
HHBB03-03 | 3 | φ7.1*3 | 2.2/0.8 | 11/21 | |
HHBB05-02 | 5 | φ11.2*2 | 2.8/0.9 | 11/21 | |
HHBB7.5-03 | 7.5 | φ11.2*3 | 1.8/0.6 | 11/21 | |
HHBB10-04 | 10 | φ11.2*4 | 2.8/0.9 | 11/21 | |
| |||||
Model | H (mm) | A (mm) | B (mm) | D (mm) | E (mm) |
HHBB0.5-01 | 635 | 460 | 230 | 288 | 165 |
HHBB01-01 | 650 | 520 | 260 | 300 | 176 |
HHBB01-02 | 660 | 460 | 230 | 288 | 165 |
HHBB1.5-01 | 770 | 615 | 295 | 430 | 265 |
HHBB02-01 | 770 | 615 | 295 | 430 | 265 |
HHBB02-02 | 815 | 520 | 260 | 300 | 236 |
HHBB2.5-01 | 830 | 615 | 295 | 430 | 165 |
HHBB03-01 | 830 | 615 | 295 | 430 | 165 |
HHBB03-02 | 930 | 615 | 295 | 430 | 320 |
HHBB03-03 | 940 | 520 | 260 | 350 | 205 |
HHBB05-02 | 1015 | 615 | 295 | 430 | 325 |
HHBB7.5-03 | 1200 | 615 | 295 | 505 | 320 |
HHBB10-04 | 1190 | 630 | 315 | 890 | 445 |


Changzhou Pankuang Hoisting Machinery Co., Ltd. Is a company committed to providing customers with one-stop material handling solutions.
It’s not only a professional manufacturer of which engaged in the research, design, manufacture, sales, installation and maintenance of cranes, including overhead crane, gantry crane and jib crane.
The company has experienced technical personnel, advanced production technology, perfect testing methods, and a normal operating quality assurance system. During the production process, it strictly implements the ISO9001: 2000 international quality system standard.
Meanwhile, it’s also a trader acting as an agent of many brand products including electric hoist, wire rope hoist, chain hoist and intelligent lifting assist devices. All of these brands are ISO9001, ISO14001, OHASA18001 certified.
The products are of reliable quality and leading performance, covering more than 20 countries and regions around the world, and are widely used in machinery, metallurgy, automobile, shipbuilding, glass, paper, locomotive and other industries. PanKuang has successfully designed and manufactured unique special lifting equipment for corporate construction projects.
Pankuang welcomes all to visit the factory and negotiate. Reliable product quality and perfect after-sales service are always its principle standards!
