500 кг до 5 тонн сверхмощный 200 м длинный кабель строительный материал подъемная лебедка

Share on:

Price:650,00 $ - 700,00 $
Price in USD:Details


Product Overview


ALLMAN 500kg to 5 Ton Heavy Duty 200m Long Cable Construction Material Lifting Winch

Product Description

Brief Introduction :


Buy Construction Material Lifting Winch  from us . Allman Company has its own factory , producing heavy duty electric winch , capacity include 500kg , 750kg , 1000kg , 1600kg , 2 ton , 3 ton , 5 ton and 10 ton . Power voltage can be 220V , 380V , 440V .  Dual voltage 220V/380V , 220V/440V power can be switchable on one winch . Allman electric cable winch hoist has passed CE certificate .


ALLMAN Electric Construction Winch Overview :

electric winch.JPG.jpg

mining winch.jpg


 Product Information :


Product Name Electric Construction Material Lifting Winch
Power Supply 220V - 480v , 3 Phase , 50/60Hz
Control Voltage 24V
Cable Length standard 60m , 100m , 150m , 200m, can be customized
Winch Motor WEG brand , 3 years warranty
Brake Electro-magnet braking system
Cable Ungalvanized , 6*19+FC , 6*37+FC
Hook Forged and heat treated , with safty latch
Gears CNC machined with high precise , superior quality alloy and heat treated .
Winch Installation installation mounting plate with holes
Certificate CE
Color Yellow + Blue


Technical Parameters of ALLMAN Electric Construction Winch



Rated Capacity


Rated Speed







Work Level

Rope Diameter


Wire Rope


AMW-1000100013~193.0 43220-48050/60M51160
AMW-1600160012~184.0 43220-48050/60M513100


2ton winch specification.jpg


 Winch Size :

Model A(mm)B(mm)C(mm)D(mm)E(mm)F(mm)G(mm)H(mm)I(mm)
AMW-5004 - Ø13400340890140238880460386
AMW-7504 - Ø13400340890140238880460386
AMW-10004 - Ø13400340890140238880460386
AMW-16004 - Ø1358534010751404221080460386
AMW-22004 - Ø186005108001803101225655565
AMW-32004 - Ø187005109001804101365655565
AMW-36004 - Ø227005109001804101390655565


 ALLMAN Electric Construction Winch Structure Features :


allman electric winch.jpg


  • Electric winch mounting plate : using welded channel steel , with fixed holes , very easy for the wire rope winch installation .

  • Winch frame structure and gear box : using high quality ductile cast iron FCD-45# steel , with good extension and strong .

  • Transmission gear : using superior quality steel and heat treated , processed by CNC machine to reach high precise level ,  wearable , low noise and drive smoothly .

  • The electric winch motor : Equipped with the world  famous brand WEG motor , protection grade IP55 , warranty 3 years .

  • Brake type  : Using electromagnetic brake , which can automatic braking once power off .

  • The drum driving mechanism : ALLMAN's electric heavy duty wire rope electric winch drum driving adopts planetary gear transmission mode. Which make the winch drum small in size, light in weight, compact in structure and high in carrying capacity.

  • Wire rope : Allman electrical winches use high strength hemp core wire rope. The function of the hemp core is to store lubricating oil, so that the oil on the surface of the steel wire rope can be replenished permanently, make the wire rope durable and anti-corrosion .

  • Electrical components : Using world famous brand Schneider contactor . Hand Switch IP 65 .

Applications :


ALLMAN self owned factory made high quality electric winch hoist is a king of industrial construction lift winch machine  , also known as called electric winch,  electric cable hoist ,electric utility winch , electric windlass. With high configuration and good performance , long wire rope length . Allman electric winch hoists are quite suitable for the high and vertical lifting as well as horizontal pulling site . It is the best choice for construction material lifting and mining project use .


Production Show  in factory :

industrial winch .jpg

electrical winches.jpg   winch package.jpg


Packaging & Shipping

 packing and shipping.jpg



1. Q : Are you manufacturer or trading company ?

    A : Allman company is intergrating of mannufacturer and trading . We produce electric chain hoist and electric winches . Meanwhile , our company is a professional supplier of various lifting and material handling equipment , product include : wire rope hoist , hand chain hoist , lever hoist , hoist trolleys , hand winches , tirfor winches , lifting magets , lifting clamps , pulley block , crane scales , crane and crane parts , Aluminum and fiberglass ladders etc .

2. Q : How about your product quality ?

    A : " Quality is our company's life , Safety always comes first ."  It's our business principle and our promise to customers . Based on this , we focuse on every details about the products , from the raw material to the procession till the complete products finishing , we have stricty quality control system . At least 5 steps inspection during the whole procession .

3. Q: How about the warranty ?

    A : Usually for the electrical wearing parts , 1 years warranty . Others parts 3 years for the winch.

4. Q : Any after-sales service ?

    A: Sure , our trained team including the sales and technicians will provide you with strong after-sales service at any time .

5. Q: Can we have our OWN brand on the products ?

    A : Sure , OEM is totally acceptable .

6. Q : Whats the MOQ ?

    A : Sample order is acceptable , MOQ is 1 set .

7. Q : How about the lead time ?

    A : Lead time depends on the order quantity , If less than 10 units ,it will about 10 days . If one container , it will take around 20 days .

8.  Q : Which sea port is the nearest ?

     A :  Shanghai Port is the nearest for us , But we can ship the products as your request .

9. Q : How about the payment term ?

    A : For new customers , the first order amount less than $5000.00, 100% by TT before production . Amount over $5000,00 , 30% in advance , 70% before delivery .

Product Categories

 lifting equipment.jpg

company profile

 ALLMAN factory.JPG



CE certifications

 allman CE.JPG


ALLMAN Exhibition

1. Canton Fair : We have exhibition booth at Canton Fair every year .


allman exhibition 01.jpg

2. Overseas exhibitions , Nigeria Exhibition in 2019 .

exhibition 01.jpgexhibition 02.jpg

Contact Us




Office address: Room 1503, Building#2,No.#166, North Street, Gangzha District, Nantong city, Jiangsu Province, China

Factory address: No. 38 Tansu Road, Gangzha District, Nantong city, Jiangsu Province, China

Email: allman@allmanindustry.com

 Tel : 0086-513-55019909
