Components |
bobbin, ferrite core, silicon steel sheet, copper wire, copper foil, insulation tape, margin tape, TFL tube, expoy |
Bobbin Material |
bakelite/ phenolic/ plastics |
Shape Type |
horizontal / vertical / SMD |
Inductance Range |
1uH-100H |
Working Frequency Range |
50Hz --300KHZ |
Output Power |
0.1W-3000W |
Output Voltage |
0.1V-10000V |
Output Current |
0.01A-100A |
Operating Temperature |
-15℃~+80℃ |
Storage Temperature |
-25℃~+85℃ |
Storage Humidity |
30% ~ 90% |
Test Items |
Ø Turns ratio |
Ø Inductance |
Ø Phase test |
Ø Inductance leakage |
Ø DC resistance test |
Ø Withstand voltage |
Ø Insulation resistance |
Certification |
ISO9001:2015, ISO14001:2015, UL, ROHS, CQC |
MOQ |
1000 pcs |
OEM/ODM |
acceptable |
Sample |
free |
Sample Time |
3-5 working days |
Package |
EPE foam + export carton, or plastic tray+export carton |
Delivery time |
15-18 working days against deposit |
Features |
Large transmission power |
Low loss |
Low temperature rise |
Stable performance |
Applications |
1. switching power supply |
2. electrical home appliance |
3. medical equipments |
4. communication device |
5. solar energy and inverter |
6. car charging pile and car charger |
7. security products and smart home |
