Gree большой емкости 60000Btu Промышленный Шкаф напольный блок переменного тока напольный кондиционер
- Category: Other Air Conditioners >>>
- Supplier: Moyu Technology Co. Ltd Zhuhai
Share on (1600320382611):
Product Overview
Description
Product Description
Product Paramenters
Model | GVH24AL-K3DNC7A | GVH48AH-K3DNC7A | GVH60AH-K3DNC7A | |||||||
Function | Cooling/Heating | Cooling/Heating | Cooling/Heating | |||||||
Capacity | Cooling | Btu/h | 24600 | 45000 | 51860 | |||||
Heating | Btu/h | 25600 | 49100 | 62000 | ||||||
Power Supply | 1Ph, 220-240V~,50Hz | |||||||||
Power Input | Cooling | W | 2250 | 4328 | 5570 | |||||
Heating | W | 2080 | 4200 | 5400 | ||||||
Rated Current | Cooling | A | 18 | 11.0 | 25.83 | |||||
Heating | A | 19 | 9.0 | 23.35 | ||||||
Airflow Volume | Indoor | m3/h | 1400/1150/1050/900 | 1800/1630/1420/1250 | 1800/1630/1420/1250 | |||||
Indoor Unit | ||||||||||
Sound Prower Level | Indoor | dB(A) | 69/57/53/50 | 53/50/48/45 | 51/49/47/45 | |||||
Outline Dimension | WxHxD | mm | 507x1770x320 | 1032x1250x412 | 581x1870x395 | |||||
Package Dimension | WxHxD | mm | 623*1988x440 | 1113x1400x453 | 738x2083x545 | |||||
Net Weight/Gross Weight | Indoor | kg | 40/54 | 59/85 | 59/85 | |||||
Sound Power Level | Outdoor | dB(A)(SH/H/M/L) | 60 | 60 | 61 | |||||
Piping Connection | Gas | mm | φ16 | φ19 | φ19 | |||||
Liquid | mm | φ6 | φ12 | φ19 | ||||||
Outline Dimension | WxHxD | mm | 955x700x396 | 581x1870x395 | 1000x1365x427 | |||||
Package Dimension | WxHxD | mm | 1029x735x458 | 2083x738x545 | 1140x1505x478 | |||||
Net Weight/Gross Weight | Outdoor | kg | 69/74 | 106/117 | 126/137 | |||||
Loading Quantity | 40'GP | sets | 66 | 34 | 32 | |||||
40'HQ | sets | 71 | 40 | 38 | ||||||
