Top Brand 42m Truck Mounted Concrete Pumps Machine
- Category: >>>
- Supplier: Changyuan Nongjian Machinery Equipment Co. Ltd
Share on (1600329914367):
Product Overview
Description
Details Images
Product Paramenters
42m pump truck | ||||
底盘 Chassis | 底盘 Chassis | 东风牌 Dongfeng | ||
排放标准 Emission Standards | 国五 CHINA V | |||
发动机 Engine | 玉柴 Yuchai | |||
发动机功率/转速 Engine power/speed | 199/243kw/2100rpm | |||
轴距 Wheelbase | 4350+1300mm | |||
最大行驶速度 Maximum travel speed | 80km/h | |||
整车接近/远离角 Vehicle approach/away angle | 21°/11.5° | |||
臂架系统 Boom system | 臂架最大垂直高度 Maximum vertical height of boom | 40.1m | ||
臂架水平布料半径 Boom horizontal cloth radius | 36m | |||
各节臂长(1-5) boom length of each section (1-5) | 8850/6700/6500/7100/7100mm | |||
各节臂转动角度 Rotation angle of each boom | 90/180/180/229/212° | |||
转台旋转角度 Turntable rotation angle | ±360° | |||
臂架控制模式 Boom control mode | 负载敏感的比例控制 Load-sensitive proportional control | |||
臂架折叠方式 Boom folding method | M-L型 (五节臂架) M-L type (Five-section boom) | |||
前支腿横跨距离 Front leg spanning distance | 6800mm | |||
后支腿横跨距离 Back leg span distance | 8350mm | |||
前后支腿纵向距离(MM) Longitudinal distance between front and rear legs (MM) | 6800mm | |||
尺寸&重量 Size & weight | 总尺寸 Total dimension（L*W*H） | 11350*2500*3850mm | ||
总重量 Total weight | 25000kg | |||
泵送系统 Pumping system | 理论泵送次数(次/分钟) Theoretical pumping times (times/min) | 18~26 | ||
最大上料高度 Maximum feeding height | 1450mm | |||
液压油箱容积 Hydraulic tank capacity | 500L | |||
理论混凝土排量 Theoretical concrete displacement | 83-140m³/h | |||
Company Profile
Company profile
Changyuan City Agricultural Construction Machinery Equipment Co., Ltd. is located in the Automobile Industrial Park of Changyuan City, Henan Province. It is a concrete pump truck manufacturer integrating R&D, production, sales and service of concrete pump trucks.
The company has fixed assets of 60 million yuan, covers an area of 240 acres, and has a construction area of 40,000 square meters. It has standardized workshops, 3 small and medium-sized concrete pump truck production lines, with a total investment of 200 million yuan, and an annual output of 500 small and medium-sized concrete pump trucks.
Changyuan Agricultural Construction specializes in the production of small and medium-sized concrete pump trucks with a complete range of products. The main products are 30-meter, 33-meter, 38-meter, 42-meter mixer pump trucks, and 30-meter, 33-meter, 38-meter, 42-meter, 47-meter, 50-meter, 58-meter, and 63-meter pump trucks. The medium and small concrete pump truck produced by the company has the characteristics of convenient operation, good reliability of the whole machine, high working efficiency, low fuel consumption and low noise.
The small and medium-sized pump truck developed and produced by the company has obtained a number of patented technologies. In 2017, our company's single-axle 37-meter concrete pump truck won the "BICES China International Engineering Machinery Innovation Product Award". In 2019, the company was rated as "Science and Technology SMEs in Henan Province" by the Henan Provincial Department of Science and Technology; in 2019, it was recognized as "Henan Province Enterprise Technology Center"; in 2020, the company successfully passed the ISO9001 quality management system, ISO14001 environmental management system, and OHSAS 18001 Occupational health and safety management system certification. A dazzling laurel crown won widespread praise from the society, and at the same time it is also a sign of the rapid development of Changyuan Agricultural Construction.
In recent years, the company insists on scientific research and reputation-based, actively introduces advanced technology at home and abroad, adopts new technology and scientific and strict testing methods to make the performance of the concrete pump truck and concrete mixing integrated pump truck more reliable, which is widely accepted by the construction industry. Favor of colleagues. The products are sold well in various provinces, cities and regions and have gone abroad, exported to the Philippines, Singapore, Indonesia, Kyrgyzstan and other countries, and have won unanimous praise from customers.
The company has fixed assets of 60 million yuan, covers an area of 240 acres, and has a construction area of 40,000 square meters. It has standardized workshops, 3 small and medium-sized concrete pump truck production lines, with a total investment of 200 million yuan, and an annual output of 500 small and medium-sized concrete pump trucks.
Changyuan Agricultural Construction specializes in the production of small and medium-sized concrete pump trucks with a complete range of products. The main products are 30-meter, 33-meter, 38-meter, 42-meter mixer pump trucks, and 30-meter, 33-meter, 38-meter, 42-meter, 47-meter, 50-meter, 58-meter, and 63-meter pump trucks. The medium and small concrete pump truck produced by the company has the characteristics of convenient operation, good reliability of the whole machine, high working efficiency, low fuel consumption and low noise.
The small and medium-sized pump truck developed and produced by the company has obtained a number of patented technologies. In 2017, our company's single-axle 37-meter concrete pump truck won the "BICES China International Engineering Machinery Innovation Product Award". In 2019, the company was rated as "Science and Technology SMEs in Henan Province" by the Henan Provincial Department of Science and Technology; in 2019, it was recognized as "Henan Province Enterprise Technology Center"; in 2020, the company successfully passed the ISO9001 quality management system, ISO14001 environmental management system, and OHSAS 18001 Occupational health and safety management system certification. A dazzling laurel crown won widespread praise from the society, and at the same time it is also a sign of the rapid development of Changyuan Agricultural Construction.
In recent years, the company insists on scientific research and reputation-based, actively introduces advanced technology at home and abroad, adopts new technology and scientific and strict testing methods to make the performance of the concrete pump truck and concrete mixing integrated pump truck more reliable, which is widely accepted by the construction industry. Favor of colleagues. The products are sold well in various provinces, cities and regions and have gone abroad, exported to the Philippines, Singapore, Indonesia, Kyrgyzstan and other countries, and have won unanimous praise from customers.
Certifications
Health and safety management system certification
Environmental management system certification
Quality management system certification
Henan Science and Technology Enterprise
Provincial Enterprise Technology Center
Innovative development type advanced enterprise
Construction Site
House construction
Shopping mall construction
Bridge construction
High-speed rail construction
Our Workshop
Plasma and laser cutting
machining
Boom welding
Turntable making
Painting
Whole equipment checking and testing
FAQ
Q1:Are you manufacturer factory or trading company?
We are original factory,we have our own werehouse and workshop.
R&D center, professional sales and after-sales team.
We are original factory,we have our own werehouse and workshop.
R&D center, professional sales and after-sales team.
75% of our products are exported to all over the world.
Asia:India,Philippines,Thailand,Burma,Vietnam,Bangladesh,Kazakhstan,Turkmenistan,etc.
Middle east:Saudi Arabia,UAE,Jordan,Oman,Syria,Pakistan,etc.
Europe:Russia,Ukraine,Belarus,Bulgaria,etc.
Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc.
South America:Brazil,Peru,Chile,Cuba,Venezuela,Mexico,etc.
Oceania:Papua New Guinea,Australia,etc.
Q3:What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers.TT,L/C,D/P,depending on the
cooperation time,country and contract value.
Q4:What kind of logistic service do you supply?
FOB, CIF, DAP, DDP or other ways according to your request.
Middle east:Saudi Arabia,UAE,Jordan,Oman,Syria,Pakistan,etc.
Europe:Russia,Ukraine,Belarus,Bulgaria,etc.
Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc.
South America:Brazil,Peru,Chile,Cuba,Venezuela,Mexico,etc.
Oceania:Papua New Guinea,Australia,etc.
Q3:What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers.TT,L/C,D/P,depending on the
cooperation time,country and contract value.
Q4:What kind of logistic service do you supply?
FOB, CIF, DAP, DDP or other ways according to your request.
