INTRODUCTION

Based on the mature electric control reversing concrete pump, HAMAC has developed the full hydraulic control concrete pump with excellent performance by our experienced engineers who are in this field many years.

PERFORMANCE

1. Radiator: adopts the air-cooled plate-fin radiator to ensure that the system could operate in a maximum temperature allowed.
2. The main oil pump: adopts the German Hawe / Rexroth / Japanese Kawasaki series.
3. Lubrication system: adopts the automatic multi-point lubrication technology featuring one to one lubrication with better efficiency and the extending service life of wearing parts.
4. Power system: the power of motor series uses the well-known domestic and foreign brands: Yantai motor, Qingdao motor, Siemens Beide motor.
5. Diesel Series: power system employs the Lovol or Deutz diesel engine;
6. Electrical parts: the main electrical products adopts Schneider , LG products to the reliability of the electronic control system.
7. Hydraulic Hose Fittings: adopts the US Eaton products to ensure the safety of the hydraulic system, no leakage.
8. Large cylinder seals: Large cylinder seals adopts the US Parker products.
9. S valve: employing the manganese steel overall casting, the wearing surface adopts wear-resistant materials featuring the dual advantages of pressure and abrasion resistant.
10. Glasses plate cutting ring: glasses plates and cutting ring inlaid adopts the carbide hard to ensure a durable design.
11. Pistons: adopts the imported materials and precision machining, with excellent qualities: hydrolysis resistance, wear resistance and high temperature resistance.

MANUFACTURING PROCESS OF DHBT40 Diesel Engine Driven Concrete Pump



SPECIFICATION

Items			Units	Parameters
				DHBT40-10-82R
Whole performance of machine		Max. theoretical concrete output (L./H.)	m3/h	40/26
		Max. concrete pumping pressure (H. /L.)	MPa	10/7.6
		Distribution valve type		S Valve
		Concrete cylinder diameter×stroke	mm	1800×1300
		Hopper capacity×feeding height	L×mm	400×1100
		Outlet diameter	mm	150
Power system		Diesel engine model		WEICHAI WP4G110E220
		Electrical engineering power	kW	82
		Rotate speed	r/min	2100
Hydraulic system		Circuit type		Open circuit
		Pumping system pressure	MPa	31.5
		Mixing system pressure	MPa	6-8
		Capacity of oil tank	L	370
	Maximum deliver height/horizontal distance		m	120/500
Other parameters		Max. aggregate diameter	mm	30/40mm for different aggregates
		Inside diameter of delivering pipe	mm	125
		Dimensions:length×width×height	mm	5000×1850×1700
		Total weight	kg	4500



Note: Our products are being updated constantly, if there is any data discrepancy, please refer to the actual product.
