AFM3020 Air flow sensor
1. The AFM3020 sensor is Aoson Electronics' gas flow sensor, which measures the flow of air, oxygen and other non-corrosive gases with superb accuracy.
2. Using 5V power supply voltage, with digital I2C interface. Output measurements are calibrated internally and temperature compensated.
3. Internally, a thermal sensor chip is connected to a high-performance CMOS microprocessor with integrated 24-bit AD acquisition.The gas flow is measured by the thermal sensor chip, ensuring very fast signal processing time and higher accuracy than similar products.
2. Using 5V power supply voltage, with digital I2C interface. Output measurements are calibrated internally and temperature compensated.
3. Internally, a thermal sensor chip is connected to a high-performance CMOS microprocessor with integrated 24-bit AD acquisition.The gas flow is measured by the thermal sensor chip, ensuring very fast signal processing time and higher accuracy than similar products.
Specifications
Item | Conditions | Min | Typ | Max | Unit | ||||
Output | IIC | ||||||||
Power supply | VDD | 4.75 | 5 | 5.25 | V | ||||
Flow range | -10 | 200 | SLM | ||||||
Accuracy | 2.5% | ||||||||
Operating temperature | 0 | 60 | ℃ | ||||||
Testing gas | Air/N2/O2 | ||||||||
Working pressure | 1.3 | bar | |||||||
Calculation method | |||||||||
Application
1. Environmental monitoring 2. Ventilator / respirator
3. Anesthesia machine 4. Spraying machine
5. Medical apparatus and instruments 6. The automatic control
7. Experimental apparatus
3. Anesthesia machine 4. Spraying machine
5. Medical apparatus and instruments 6. The automatic control
7. Experimental apparatus
