bore hole solar pump system 4 inch solar water pump for irrigation purpose Solar deep well water pump for bore well
- Category: Solar Water Pump >>>
- Supplier: Hangzhou Solar Photoelectricity Co. Ltd.
Share on (1600368228752):
Product Overview
Description
Product Description
Specification
Plastic Impeller Series | SS Impeller Series | Screw Pump Series | |||||
Ref No. | 3SBY3.2/106-D96/1000 | 4SBY7.0/110-D110/1500 | 4SBB6.5/98-D110/1600 | 3SBL1.3/50-D24/140 | 3SBL2.1/120-D72/750 | ||
Motor | DC Brushless Motor | DC Brushless Motor | DC Brushless Motor | DC Brushless Motor | DC Brushless Motor | ||
Controller | MPPT | MPPT | MPPT | MPPT | MPPT | ||
Pump Body | stainless steel | stainless steel | stainless steel | stainless steel | stainless steel | ||
Outlet/Culinder | Brass | Brass | stainless steel | stainless steel | stainless steel | ||
Impeller | plastic | plastic | stainless steel | / | / | ||
Screw Sleeve | / | / | / | rubber | rubber | ||
Screw | stainless steel | stainless steel | stainless steel | stainless steel | stainless steel | ||
Rated Voltage | 96V | 110V | 110V | 24V | 72V | ||
Voltage Range | 60~180V | 60~180V | 60~180V | 18~50V | 50~150V | ||
Rated Power | 1000W | 1500W | 1600W | 140W | 750W | ||
Rated Current | 10A | 12A | 12A | 8A | 10A | ||
Max Flow | 3.2m³/h | 7.0m³/h | 6.5m³/h | 1.3m³/h | 2.1m³/h | ||
Max Head | 106m | 95m | 98m | 50m | 120m | ||
Outlet Dia. | 1" | 1.25" | 1.25" | 1" | 1" | ||
Outline Dia. | 3" | 4" | 4" | 3" | 3" | ||
Solar Panel | 330w/36v | 330w/36v | 330w/36v | 300w/30v | 330w/36v | ||
Solar Panel Qty | 4pcs | 8pcs | 8pcs | 1pc | 3pcs | ||
Advantage of DC solar pump
1.DC Brushless Permanent-magnetic synchronous motor for solar power dc submersible water pump, efficiency improved 10%-15%
2.304 S/S pump shaft; High-quality bearing; Alloy mechanical seal，long life and reliable operation
3. Motor coil is made by automatic winding machine with centralized winding technology, motor efficiency is much improved.
4. Intelligent water shortage protection: the pump stops working automatically when there is no water in the well, and
automatically start working 30 minutes later.
5. Controller: MPPT function; frequency conversion function; Automatically working function; water proof and leak-proof.
6. Digital display of power, voltage, current, speed and other working conditions. 7. High/low voltage protection, over current
/overload protection
2.304 S/S pump shaft; High-quality bearing; Alloy mechanical seal，long life and reliable operation
3. Motor coil is made by automatic winding machine with centralized winding technology, motor efficiency is much improved.
4. Intelligent water shortage protection: the pump stops working automatically when there is no water in the well, and
automatically start working 30 minutes later.
5. Controller: MPPT function; frequency conversion function; Automatically working function; water proof and leak-proof.
6. Digital display of power, voltage, current, speed and other working conditions. 7. High/low voltage protection, over current
/overload protection
Application
