500W 400W 300w 200w 150w 120w 100w 80w outdoor led lighting led driver ip67 waterproof led power supply
- Category: Lighting Accessories >>>
- Supplier: Zhongshan Top Optoelectronics Technology Co. Ltd
Share on (1600408580076):
Product Overview
Description
LED Driver 50w 100w Constant Current Waterproof IP67 for Outdoor Power Supply 36v 48v Power Source
Features:
Nominal voltage:100-277Vac / Full range
Power factor: ≥ 0.95 / Full range
Total Harmonic Distortion(THD): ≤ 10%
Protections: Open circuit / Short circuit/Overload
ervoltage Cut off:Input overvoltage & undervoltage cut off
OTP: Tc ≥ 85℃,Reducing Current
Constant current design
Low cost , high reliability
Current ripple: < 30%
Cooling by free air convection
Surge:4KV/6KV (L~N)
Can withstand input voltage of 440V for 8hrs
Suitable for LED flood lighting,street lighting
7 year warranty, MBTF > 30000 hours
General Specification
AC input voltage range : 85~440Vac
AC input frequency range :47~63Hz
AC inrush current (max.) :Cold start , 20A at 230Vac,
Full load Over voltage protection : 115% ~135% rated output volteage
Turn on delay time : < 1.0 S@ Full load
Dielectric strength : >3.75KV (L~N)
Ingress protection : IP65
Working temperature : -30 ~+ 65℃
Working humidity : 20%~90% R.H.
Storage environment : -40 ~+ 85℃, 0%~95% R.H.
Safety standards :Design refer to EN60950-1, EN61347-2-13
EMC standards :Design refer to EN55015,EN61000-3-2,EN61000-3-3
Connection
Input : 1²×3C (Line: Brown, Neutal: Blue, Ground: Yellowish green ), Length:40cm
Output : 0.75²×2C (+: Red, -: Black) , Length:25cm
Dimension ( L×W×H )(mm) :135x47x32.5
