New Promotion 12v/24v Hydraulic Industrial Electric Winch Manufacturers

Product Overview

Description



Rated Line Pull	22000 lbs (9966kgs) Single-line
Motor	12V 8.9hp, 24V8.9hp, Series Wound
Control	Remote switch, 12’ (3.7m) lead
Gear Train and Reduction Ratio	3 stage planetary ,m3=2 4big star gears 246.8
Clutch	100% Automatic Clutch System
Braking	Machine brake in gear box
Drum Size	Diameter φ2.5”(φ63.5mm) Length 8.82”(224mm)
Wire Rope	Diameter φ1/2”(φ12mm) Length 115’(35m)
Fairlead	4-way heavy duty roller fairlead
Recommended Battery	650CCA minimum for winching
Battery Leads	Diameter 12V-φ25mm2 24V-φ15mm2 Length 72”(1.83mm)
control Box	Waterproof control box
Finish	Customized
weight	95lbs (43kgs)
Overall Dimensions	(L×W×H)22.9”×7.7”×8.5” (582mm×196mm×216mm)
Mounting Bolt Pattern	4-M10 10±0.015IN×4.5±0.01IN(254±0.4 mm×114.3±0.2mm)

Q: What's your sample policy?

A: Yes, We can supply sample if we have parts in stock.But customer afford the sample costand courier cost.

Q: Do you test all products before delivery?

A: Yes, we have 100% test before delivery.

Q: Whether you could make your products by our color?

A: Yes, The color of products ca be customized if you can meet our MOQ.

Q: Whether you could make our brand on your products?

A: Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.

Q: How long is the production lead time?

A: Usually, It will take 30-60days after receiving your advance payment. The specific deliverytime is depend on items and quality of your order.

Q: What is your payment term?

A: Normal is T/T 30% deposit and 70% balance against the copy of BL. LC at sight is alsoaccepted.And we can do credit insurance order on Alibaba.
