HOWO High Efficiency 15 25CBM Water Tank Truck With High And Low Level Spraying

Product Overview

Description

HOWO High Efficiency 15-25CBM Water Tank Truck With High And Low Level Spraying



Description:



Water Tank Truck have the character of high pressure, wide spraying

range, good flushing effect and so on. The flushing head universal regulation, meet

the arbitrary angle and the combination of the washing operation, the system can achieve

aerodynamic control and manual control of the two kinds of functions.



Tank external sandblasting, tank internal anti-corrosion treatment, outer surface of the senior

polyurethane topcoat, beautiful appearance. Optional mounted front and rear high jet,

with water diffusion function, a level 360 degree turn, also can be up and down 150

degree tilt. Optional medicine small flow pump, spraying configuration reel awakened

garden flowers and trees to kill the insects.





Specification:



HOWO High Efficiency 15-25CBM Water Tank Truck With High And Low Level Spraying
Chassis Model	ZZ1257N4641W
Drive Type	6×4
Engine	WD615.69, 336HP
Cabin	HW76 lengthened cab(with one sleeper, air-conditioner and two new-style seat)
Transmission	HW15710(10 forwards & 2 reverses)
Front Axle	HF9(1X9 Tons)
Driving Axle	HC16(1X16 Tons)
Clutch	hydraulically operating with air assistance
Rim/ Tire	11.00R20, Radial tyre
Wheel base	4325+1350(mm)
Capacity of tank body	21-25CBM
Spraying width of travel	14.8m
Spraying height	30m
Water sucking depth	4m
Overall dimension	9920×2496×3550mm
The curb weight	13180(Kg)
Gross weight	25000 kg
Max. speed	95km/h
Color	White, red, green, golden and so on.

Applications:



The Water tank truck is mainly used for construction of mines and other enterprises, road flushing and

dust covering in large-medium-scale cities.



Competitive Advantage:



1) High pressure, wide range of spraying good flushing effect

2) Blunt head universal adjustment, meet the arbitrary Angle and the combination of the flush operation

3) Pneumatic control and manual control system can realize two functions

4) External sandblasting processing of tank, internal anti-corrosion treatment,        Outside surface adopts advanced polyurethane paint, beautiful appearance

5) Front and back high spray is optional, water jet diffusion function, 360 degrees of rotation,

150 degree tilt up and down. Options small flow pump, spraying reel to wake insecticidal garden trees

flowers and plants

6) with all kinds of truck model, which can fulfill your requirement
7) the key parts adopt the world's top technology products

8) competitive price, cost-effective
9) quick and efficient spare parts supply bring you more convenient

10) fast delivery time, we can arrange production according to your needs exactly and quickly
