Chasis Model | ZZ1257M4647C LHD | ||||||||
Truck Brand | SINOTRUK-HOWO | ||||||||
Color | Optional | ||||||||
Dimension(Lx W xH)(unloaded)(mm) | 10350×2496×3048 | ||||||||
Tank Volume(m3) | 20m3 Tank body(thickness):5mm,material:carbon steel; sprinkling equipment both in front and in rear; special anti-corrosion treatment | ||||||||
Approaching angle/Departure angle(°) | 16/12 | ||||||||
Overhang(front/rear) (mm) | 1500/2900 | ||||||||
Wheel base (mm) | 4600+1350 | ||||||||
Max speed(km/h) | 75 | ||||||||
Curb weight(kg) | 11360 | ||||||||
Total Weight(kg) | 25000 | ||||||||
Engine (Steyr technology, made in China) | Model | WD615.97C,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | |||||||
Fuel type | Diesel | ||||||||
Power, max(kw/rpm) | 300HP | ||||||||
Emission | EURO III | ||||||||
Fuel tanker capacity (L) | 350 | ||||||||
Transmission | Model | HW13710,10 forward&2 reverse | |||||||
Brake system | Service brake | Dual circuit compressed air brake | |||||||
Parking brake | spring energy, compressed air operating on rear wheels | ||||||||
Steering system | Model | Power steering | |||||||
Front axle | HF7 disc brake Loading weight:7000kg | ||||||||
Rear axle | HW1279 Loading weight:12000kg | ||||||||
Tyre | 12.00-20 10+1spare | ||||||||
Electrical system | Battery | 2X12V/165Ah | |||||||
Alternator | 28V-1500kw | ||||||||
Starter | 7.5Kw/24V | ||||||||
Cab | HOWO76 standard cab, one sleeper with air-conditioner | ||||||||
