Product Overview

Description



Product Description


95% 99.7% Customize Alumina Ceramic Rod

95% 99.7% Customize Alumina Ceramic Rod is our main product.Mission produce various Alumina Tubes, like thermocouple protection tubes, furnace tubes, multi bores alumina tubes. Special shaped tubes can be made according to clients’ requirements. Diameter we can make from 1mm to 120mm.

We can supply Insulating Material 95% 99.7% Customize Alumina Ceramic Rod .
99.7% Polished Al2o3 Rod Alumina Ceramic Rod Technical Data:
Material : 99.7% Alumina, 95% Alumina
Max working temperature: 1800C.


High Purity 99% Alumina Al2O3 Ceramic Rod Specifications
1. Alumina Purity: 95% 99.7%
2. Working temperaure: 1800C
3. Diameter 1-45mm, length 10-1800mm



Item
Unit
Alumina
Alumina Content
wt%
99.7%
Density
g /cm3
3.90
Bending Strength
MPa ≥
450
Working Temperature
°C
1800
linear expansion coefficient
×10-6/°C
8.0
Insulation strength
Kv/mm
12
water absorption
%
<0.1-0.2
Coefficient of Thermal Conductivity
W/m•K( 20°C)
38


Detailed Images






Packing & Delivery


95% 99.7% Customize Alumina Ceramic Rod package and delivery.

1. Clean alumina ceramic rods by washing.
2. Warped with bubble plastic paper.
3. Put in wood box padded with foam board.
4. Sealed the box with screws which is easy to be opened.
5. Fragile warning stick.

Shipping Method: By sea, by Air, by express way.
